Benefits

• Standard compliance of the charging process with IEC 61851-1
• VDE EVC certified according to VDE-AR-E 2283-5/ EVC cable type as third-party approved component in the charging process
• Low toxicity of smoke in the event of fire
• Permanent connection as flexible charging cable to charging station or for permanent on-board carriage inside vehicles
• Suitable for spiralling, except for 5G6+1X0.5

Product features

• Flame-retardant according to IEC 60332-1-2 as well as halogen-free according to VDE-AR-E 2283-5/ appendices B+C, EN 50267-2-1, EN 50267-2-2, EN 50525-1/ appendix C, EN 60684-2
• UV-resistant according to EN ISO 4892-2, 2.4.20, as well as ozone-resistant according to EN 50396, 8.1.3, for outdoor use
• Flexible at low temperatures as well as water-resistant according to AD6 of HD 516 / VDE 0298-300 and VDE-AR-E 2283-5, appendix I
• Resistance to acids and alkali according to EN 60811/ VDE 0473-811
• High resistance to usual vehicle chemicals according to VDE-AR-E 2283-5, appendix G

Norm references / approvals

• <VDE> EVC cable type registration issued by the VDE according to the VDE application rule VDE-AR-E 2283-5

Design

• Fine-wire, bare copper conductor of IEC braided conductor class 5 according to IEC 60228 / VDE 0295
• Core insulations of power cores made of special, halogen-free, cross-linked elastomer EVI-2 according to VDE-AR-E 2283-5
• Core insulation control/pilot core(s): Halogen-free, special thermoplastic EVI-1 according to VDE-AR-E 2283-5
• Halogen-free, PUR outer sheath in compliance with the compound EVM-1 according to VDE-AR-E 2283-5
• Outer sheath colour: Orange similar to RAL 2003, further sheath colours on request
