ÖLFLEX® CRANE NSHTÖU
Reelable cables for low and medium mechanical stress
ÖLFLEX® CRANE NSHTÖU, VDE power and control cable 0.6 1 kV, reelable/crane/torsion-supporting braiding, rubber -25°C to +80°C, flame-retardant/oil-resistant/outdoor use
- Robust and powerful
- Suitable for outdoor use
- Integrated sheath supporting braid
Benefits
- Can be used as hawser, drum and towing cable as well as in power chains
- The integrated supporting braid prevents undesirable cable twists, and the formation of so-called corkscrew effects
Application range
- For use in hoists, transport and conveyor
systems - Reeling/unreeling during operation without fixed routing
- In dry or damp interiors, outdoors, or no more than 2 weeks without interruption in industrial water
- The application profiles for ÖLFLEX® CRANE and ÖLFLEX® LIFT cables can be found in the appendix, selection table A3
- The assembly and handling guidelines for ÖLFLEX® CRANE cables can be found in the catalogue appendix, technical table T4; for ÖLFLEX® LIFT cables, please see the catalogue appendix, technical table T5
Product features
- Flame-retardant according to IEC 60332-1-2
- Oil-resistant according to EN 60811-404
- Good chemical, thermal and mechanical resistance
- UV-resistant
Norm references / approvals
- <VDE> NSHTÖU design certification according to VDE 0250-814
Design
- Strands made of tin-plated copper wires
- Core insulation: Rubber compound, type 3GI3
- Support braid integrated in the outer sheath
- Outer sheath made of rubber compound type 5GM3
Classification
- ETIM 5.0 Class-ID: EC000057
- ETIM 5.0 Class-Description: Power cable
Core identification code
- Up to 5 cores: according to VDE 0293-308 (appendix T9)
- From 6 cores: black with white numbers
Conductor design
- Fine wire according to VDE 0295 class 5 / IEC 60228 class 5
Minimum bending radius
- Flexible use:
Cables with outer diameter < 21,5 mm: 5 x Außendurchmesser
Leitungen mit Außendurchmesser > 21.5 mm: 6.25 x outer diameter
Nominal voltage
- U0/U: 600/1000 V
Test voltage
- 4000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Current load capacity
- VDE 0298 part 4
Temperature range
- Flexible use: -25°C to +80°C
| Article number |
Number of cores and mm² per conductor |
Outer diameter (mm) |
Copper index (kg/km) |
Weight (kg/km) |
| ÖLFLEX®CRANE NSHTÖU | ||||
| 0043006 | 3 G 1.5 | 12.2 | 43.2 | 190 |
| 00430053 | 4 G 1.5 | 14.8 | 57.6 | 220 |
| 00430073 | 5 G 1.5 | 15.7 | 72 | 260 |
| 0043008 | 7 G 1.5 | 18.2 | 100.8 | 380 |
| 0043009 | 12 G 1.5 | 23.9 | 172.8 | 720 |
| 0043010 | 18 G 1.5 | 23.9 | 259.2 | 770 |
| 0043011 | 24 G 1.5 | 27. 1 | 345.6 | 1000 |
| 0043012 | 30 G 1.5 | 30.2 | 432 | 1320 |
| 0043013 | 3 G 2.5 | 13.5 | 72 | 250 |
| 00430303 | 4 G 2.5 | 16.9 | 96 | 330 |
| 00430143 | 5 G 2.5 | 18 | 120 | 390 |
| 0043015 | 7 G 2.5 | 20.6 | 168 | 510 |
| 0043016 | 12 G 2.5 | 27.4 | 288 | 970 |
| 0043017 | 18 G 2.5 | 27.4 | 432 | 1100 |
| 0043018 | 24 G 2.5 | 31.6 | 576 | 1450 |
| 0043019 | 30 G 2.5 | 36.3 | 720 | 1950 |
| 00430203 | 4 G 4 | 18.4 | 153.6 | 440 |
| 00430333 | 5 G 4 | 19.6 | 192 | 520 |
| 00430213 | 4 G 6 | 19.8 | 230.4 | 530 |
| 00430343 | 5 G 6 | 21.7 | 288 | 690 |
| 00430223 | 4 G 10 | 23.4 | 384 | 830 |
| 00430003 | 5 G 10 | 25.2 | 480 | 1000 |
| 00430233 | 4 G 16 | 25.5 | 614.4 | 1170 |
| 00430323 | 5 G 16 | 27.5 | 768 | 1400 |
| 00430243 | 4 G 25 | 32.6 | 960 | 1830 |
| 00430253 | 4 G 35 | 34.8 | 1,344.00 | 2280 |
| 00430263 | 4 G 50 | 40.6 | 1,920.00 | 3220 |
| 00430283 | 4 G 70 | 44.8 | 2,688.00 | 4200 |
| 00430293 | 4 G 95 | 51.2 | 3,648.00 | 5530 |
