Benefits

• Designed with a smaller outer diameter in comparison to conventional rubber cables to save space and weight
• Cost-saving possible due to the use of smaller drums, deflections, as well as drive motors
• If tensile forces also act on the cable during the drum process or deflection
• The central supporting element absorbs the tensile loads that occur, thereby allowing reeling, unreeling and deflection for free-hanging cables even over large distances.
• The integrated supporting braid prevents undesirable cable twists, and the formation of so-called corkscrew effects

Application range

• For use in hoists, transport and conveyor
  systems
• Wherever cables are being reeled, unreeled or forcibly guided in operation
• In dry or damp interiors, outdoors, or no more than 2 weeks without interruption in industrial water
• The application profiles for ÖLFLEX^® CRANE and ÖLFLEX^® LIFT cables can be found in the appendix, selection table A3
• The assembly and handling guidelines for ÖLFLEX^® CRANE cables can be found in the catalogue appendix, technical table T4; for ÖLFLEX^® LIFT cables, please see the catalogue appendix, technical table T5

Product features

• Halogen-free and flame-retardant (IEC 60332-1-2)
• Oil-resistant according to EN 60811-404
• Good chemical, thermal and mechanical resistance

Design

• Conductor made of bare copper wires
• Core insulation made of TPE compound
• Central supporting element
• Support braid integrated in the outer sheath
• Outer sheath made of halogen-free PUR compound
