ÖLFLEX® LIFT T
Flexible at cold temperatures, PVC lift cables with textile supporting braiding and supporting element
ÖLFLEX® LIFT T, VDE-REG., power and control cable with hemp/aramide fibre supporting element + supporting braid for lift applications, PVC, 300/500V, flame-retardant, outdoor use
- Robust cable design
- Suspension length up to 90 m
- VDE-tested and registered
Benefits
- Special cable design for a long service life
- Able to withstand mechanical stress even at high suspension lengths
- Very flexible due to extra-fine wire conductor design
Application range
- Lift cable that ensures the electrical functions in various areas of lift construction
- Suitable for use in outdoor lifts
- The application profiles for ÖLFLEX® CRANE and ÖLFLEX® LIFT cables can be found in the appendix, selection table A3
- The assembly and handling guidelines for ÖLFLEX® CRANE cables can be found in the catalogue appendix, technical table T4; for ÖLFLEX® LIFT cables, please see the catalogue appendix, technical table T5
Product features
- Flame-retardant according to IEC 60332-1-2
- Good weather resistance
- Flexible at cold temperatures
Norm references / approvals
- VDE registration under VDE reg. no. 7040
Design
- Conductor made of bare copper wires
- Special PVC-based core insulation
- Supporting element made of hemp rope or aramide fibre
- Fleece-wrapping between cable cores and the coating
- Support braid made of textile fibre blend
- Special PVC-based outer sheath
Classification
- ETIM 5.0 Class-ID: EC000826
- ETIM 5.0 Class-Description: Lift control cable
Core identification code
- Black with white numbers acc. to VDE 0293-1
Suspension length
- refer to article table
Conductor design
- Extra-fine wire according to VDE 0295, class 6/IEC 60228 class 6
Minimum bending radius
- Flexible use: 20 x outer diameter
Nominal voltage
- U0/U: 300/500 V
Test voltage
- 4000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- Flexible use: -15°C to +70°C
| Article number | Number of cores and mm² per conductor | Outer diameter (mm) | Max. suspension length (m) | Copper index (kg/km) | Weight (kg/km) |
| ÖLFLEX®LIFT T | |||||
| 0027506 | 12 G 0.75 | 18.1 | 110 | 86 | 360 |
| 0027507 | 18 G 0.75 | 18.3 | 110 | 129.6 | 460 |
| 0027508 | 24 G 0.75 | 21 | 80 | 172.8 | 530 |
| 0027001 | 7 G 1.0 | 14.5 | 80 | 67 | 225 |
| 0027002 | 12 G 1.0 | 19.2 | 80 | 115 | 410 |
| 0027008 | 18 G 1.0 | 19.5 | 70 | 172.8 | 475 |
| 0027004 | 20 G 1.0 | 20.3 | 70 | 192 | 525 |
| 0027005 | 24 G 1.0 | 22.1 | 60 | 230 | 600 |
| 0027007 | 36 G 1.0 | 28.6 | 90 | 345.6 | 950 |
| 0027006 | 28 G 1,0 + 2 x (0,5) C | 25.2 | 90 | 293 | 765 |
