ÖLFLEX® LIFT S
Flexible at cold temperatures, PVC lift cables with textile supporting braiding and steel supporting element
ÖLFLEX® LIFT S power and control cable with steel supporting element + supporting braid for lift applications with suspension lengths, flame-retardant PVC, 300/500V, braid for outdoor use
- Robust cable design
- Suspension length up to 150 m
Benefits
- Special cable design for a long service life
- Practical experience and long-term tests proved that the cable can withstand extreme stress
- High suspension lengths due to the steel supporting element
- Very flexible due to extra-fine wire conductor design
Application range
- Lift cable that ensures the electrical functions in various areas of lift construction
- Suitable for use in outdoor lifts
- The application profiles for ÖLFLEX® CRANE and ÖLFLEX® LIFT cables can be found in the appendix, selection table A3
- The assembly and handling guidelines for ÖLFLEX® CRANE cables can be found in the catalogue appendix, technical table T4; for ÖLFLEX® LIFT cables, please see the catalogue appendix, technical table T5
Product features
- Flame-retardant according to IEC 60332-1-2
- Good weather resistance
- Flexible at cold temperatures
Design
- Conductor made of bare copper wires
- Special PVC-based core insulation
- Steel support element
- Fleece-wrapping between cable cores and the coating
- Support braid made of textile fibre blend
- Special PVC-based outer sheath
Classification
- ETIM 5.0 Class-ID: EC000826
- ETIM 5.0 Class-Description: Lift control cable
Core identification code
- Black with white numbers acc. to VDE 0293-1
Suspension length
- refer to article table
Conductor design
- Extra-fine wire according to VDE 0295, class 6/IEC 60228 class 6
Minimum bending radius
- Flexible use: 20 x outer diameter
Nominal voltage
- U0/U: 300/500 V
Test voltage
- 4000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- Flexible use: -15°C to +70°C
| Article number | Number of cores and mm² per conductor | Outer diameter (mm) | Max. suspension length (m) | Copper index (kg/km) | Weight (kg/km) |
| ÖLFLEX®LIFT S | |||||
| 0027009 | 24 G 1.0 | 22.1 | 150 | 230 | 680 |
| 0027010 | 36 G 1.0 | 28.6 | 150 | 345.6 | 1092 |
