ÖLFLEX® HEAT 205 MC
Fluorinated ethylene propylene cables for demanding applications
ÖLFLEX® HEAT 205 MC – FEP connection cable for robust, chemical-resistant and space-saving for use in machine and apparatus construction at temperatures -100°C to +205°C
- Good chemical resistance
- Wide temperature application range
- Thin, light and robust
Benefits
- Space and weight-saving installation due to small cable diameters
- Resistant to most highly aggressive chemical media
- Low outgassing behaviour
- Suitable for sensor technology due to good electrical and mechanical properties
Application range
- Conventional cables cannot be used in industrial environments with very high temperatures, aggressive chemical media and limited space
- Typical fields of application
– Industrial furnace construction
– Foundries
– Chemical industry
– Power plant engineering
– Painting plant technology
– Heating elements
– Plastic processing
– Wind turbine engineering - Sensor systems, e.g. fill level sensors
Product features
- ÖLFLEX® HEAT 205 made of FEP
– Outstanding resistance against acids,
solvents, lacquers, petrol, oils
and many other chemical media
– Flame-retardant
– High dielectric strength and
abrasion-resistance
– Low water absorption
– Resistant to microbes
– Adhesion-free insulation materials
– Weather- and ozone-resistant
– Hydrophobic and dirt-repellent
– High elongation capacity and tear
resistance
– Resistant against hydraulic fluids - Flame-retardant according to IEC 60332-1-2
Design
- Fine-wire, tin-plated copper conductor
- FEP-based core insulation
- Cores twisted together
- FEP-based outer sheath, black
Classification
- ETIM 5.0 Class-ID: EC001578
- ETIM 5.0 Class-Description: Flexible cable
Core identification code
- Up to 5 cores colour-coded according to VDE 0293-308
From 7 cores ÖLFLEX® colour code, refer to appendix T7
Conductor design
- Fine wire according to VDE 0295, class 5 / IEC 60228 class 5 from 0.5 mm²
Minimum bending radius
- Occasional flexing: 15 x outer diameter
- Fixed installation: 4 x outer diameter
Nominal voltage
- U0/U: 300/500 V
Test voltage
- 2500 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- Fixed installation: -100°C to +205°C
| Article number |
Number of cores and mm² per conductor |
Outer diameter (mm) |
Copper index (kg/km) |
Weight (kg/km) |
| ÖLFLEX®HEAT 205 MC | ||||
| 0091200 | 2 X 0.25 | 3.1 | 5 | 17.2 |
| 0091201 | 3 G 0.25 | 3.3 | 7.5 | 22.2 |
| 00912023 | 4 G 0.25 | 3.6 | 10 | 27.5 |
| 0091210 | 2 X 0.5 | 3.8 | 9.8 | 21.6 |
| 0091211 | 3 G 0.5 | 4 | 14.7 | 32.8 |
| 00912123 | 4 G 0.5 | 4.4 | 19.6 | 44.4 |
| 0091220 | 2 X 0.75 | 4.2 | 14.4 | 31.5 |
| 0091221 | 3 G 0.75 | 4.6 | 21.6 | 46.1 |
| 00912223 | 4 G 0.75 | 4.9 | 29 | 57.9 |
| 0091230 | 2 X 1 | 4.5 | 19 | 41.6 |
| 0091231 | 3 G 1 | 4.8 | 29 | 55.6 |
| 00912323 | 4 G 1 | 5.3 | 38 | 70 |
| 0091100 | 3 G 1.5 | 5.6 | 43 | 70 |
| 00911033 | 4 G 1.5 | 6.1 | 58 | 98 |
| 00911013 | 5 G 1.5 | 6.8 | 72 | 117 |
| 0091102 | 7 G 1.5 | 7.4 | 101 | 184 |
| 0091236 | 3 G 2.5 | 6.6 | 72 | 86 |
| 00912353 | 4 G 2.5 | 7.3 | 96 | 115 |
| 00912373 | 5 G 2.5 | 8.2 | 120 | 144 |
| 00912423 | 4 G 4 | 8.7 | 154 | 180 |
| 00912433 | 5 G 4 | 9.6 | 192 | 225 |
