Benefits

• Space and weight-saving installation due to small cable diameters
• Resistant to most highly aggressive chemical media
• Low outgassing behaviour
• Suitable for sensor technology due to good electrical and mechanical properties

Application range

• Conventional cables cannot be used in industrial environments with very high temperatures, aggressive chemical media and limited space
• Typical fields of application
  – Industrial furnace construction
  – Foundries
  – Chemical industry
  – Power plant engineering
  – Painting plant technology
  – Heating elements
  – Plastic processing
  – Wind turbine engineering
• Sensor systems, e.g. fill level sensors

Product features

• ÖLFLEX® HEAT 205 made of FEP
  – Outstanding resistance against acids,
  solvents, lacquers, petrol, oils
  and many other chemical media
  – Flame-retardant
  – High dielectric strength and
  abrasion-resistance
  – Low water absorption
  – Resistant to microbes
  – Adhesion-free insulation materials
  – Weather- and ozone-resistant
  – Hydrophobic and dirt-repellent
  – High elongation capacity and tear
  resistance
  – Resistant against hydraulic fluids
• Flame-retardant according to IEC 60332-1-2

Design

• Fine-wire, silver-plated copper conductor
• PTFE-based core insulation
• Cores twisted together
• Tin-plated copper braiding
• Outer sheath: FEP-based, white
