ÖLFLEX® HEAT 260 GLS
Steel-armoured PTFE tank cables for increased mechanical stress
ÖLFLEX® HEAT 260 GLS – PTFE connection cable, GL-certified and steel wire armouring for increased mechanical load in ship and diesel engine building up to +260°C
- Good thermal and mechanical properties
- Robust cable design
- GL – Germanischer Lloyd certified
Benefits
- Close-meshed braid made of galvanised steel wires protects against mechanical damage
- Small outer diameters for maximum saving of space and weight
- Germanischer Lloyd certification for use with ship diesel engines
Application range
- Extreme temperatures and mechanical stress require special insulated and armoured cables
- Main applications
– Shipbuilding
– Signal systems
– Monitoring systems
– Diesel engines
– Steam boiler units
– Turbine manufacturing - Electronics for industry and shipping, ship electrics
Product features
- Flame-retardant
- Stress crack resistant in case of frequent ambient temperature fluctuations
- High dielectric strength and high abrasion resistance
- High elongation and tear resistance
- Only suitable for installation in dry conditions
Norm references / approvals
- Germanischer Lloyd (GL) certificate no. 5449871 HH
Design
- Fine-wire strand made of nickel-plated copper
- PTFE-based core insulation
- Cores twisted together
- Impregnated glass fibre braid
- Galvanised steel wire braiding
Classification
- ETIM 5.0 Class-ID: EC001578
- ETIM 5.0 Class-Description: Flexible cable
Core identification code
- Up to 5 cores: according to VDE 0293-308 (appendix T9)
- 7-core version:
gn/ye, bl, bn, bk, bk, bk, tr
Conductor design
- Fine wire according to VDE 0295 class 5 / IEC 60228 class 5
Minimum bending radius
- For fixed installation:
5 x cable diameter
Nominal voltage
- U0/U 300/500V
according to GL: 250 V
Test voltage
- 1500 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- Fixed installation: -190°C to +260°C
- according to GL: +205°C
| Article number |
Number of cores and mm² per conductor |
Outer diameter (mm) |
Copper index (kg/km) |
Weight (kg/km) |
| ÖLFLEX® HEAT 260 GLS | ||||
| 0091120 | 2 X 1.5 | 5.7 | 29 | 93 |
| 0091121 | 3 G 1.5 | 6.1 | 43 | 102 |
| 00911223 | 4 G 1.5 | 6.6 | 58 | 130 |
| 00911233 | 5 G 1.5 | 7.3 | 72 | 149 |
| 0091124 | 7 G 1.5 | 8 | 101 | 180 |
