ÖLFLEX® HEAT 350 MC
Suitable for use in ambient temperatures from -50°C to +350°C
ÖLFLEX® HEAT 350 MC – glass fibre connection cable for use in blast furnace, power plant, motor, apparatus and luminaire construction at temperatures up to +350°C
- Voltage class 230/400 V
- For use in dry conditions
Benefits
- Low conductor resistance due to the nickel-plated copper conductors
- Wide operating temperature range allows versatile use in applications in thermal class C (>180°C)
Application range
- Blast furnaces and glassworks
- Chemical and power station construction
- Motor and furnace construction
- Extrusion and drying systems
- Lighting, apparatus and instrument construction
Product features
- Flame-retardant
- Halogen-free
- Only suitable for installation in dry conditions
- ÖLFLEX® HEAT 1565 MC is recommended if the peak temperature of the application may briefly go beyond 350°C
Design
- Fine-wire strand made of nickel-plated copper
- Core insulation made of glass fibre covering and impregnated glass fibre braid
- Cores twisted together
- Outer sheath made of impregnated glass fibre braid, white (natural)
Classification
- ETIM 5.0 Class-ID: EC001578
- ETIM 5.0 Class-Description: Flexible cable
Core identification code
- Coloured according to VDE 0293-308, see appendix T9
Conductor design
- Fine wire according to VDE 0295 class 5 / IEC 60228 class 5
Minimum bending radius
- Fixed installation: 6 x outer diameter
Nominal voltage
- U0/U 230/400 V
Test voltage
- 1500 V
Temperature range
- Fixed installation: -50°C to +350°C
| Article number |
Number of cores and mm² per conductor |
Outer diameter (mm) |
Copper index (kg/km) |
Weight (kg/km) |
| ÖLFLEX® HEAT 350 MC | ||||
| 0091375 | 2 X 1 | 6.8 | 19.2 | 56 |
| 0091376 | 3 G 1 | 7.4 | 28.8 | 70 |
| 0091377 | 4 G 1 | 8.2 | 38.4 | 88 |
| 0091380 | 2 X 1.5 | 7.8 | 28.8 | 77 |
| 0091381 | 3 G 1.5 | 8.4 | 43.2 | 93 |
| 0091382 | 4 G 1.5 | 9.4 | 57.6 | 118 |
| 0091383 | 5 G 1.5 | 10.3 | 72 | 140 |
| 0091390 | 3 G 2.5 | 8.9 | 72 | 124 |
| 0091391 | 4 G 2.5 | 9.8 | 96 | 160 |
| 0091392 | 5 G 2.5 | 10.1 | 120 | 194 |
