ÖLFLEX® HEAT 1565 MC
Suitable for use in ambient temperatures between -195°C and +400°C
ÖLFLEX® HEAT 1565 MC – glass fibre connection cable for use in blast furnace, plant and power plant construction at temperatures up to +400 °C (short-term up to +1565°C)
- Short-term: up to +1565°C
- For use in dry conditions
Benefits
- Low conductor resistance due to the nickel-plated copper conductors
- Able to withstand temporary contact with molten metal or glass
Application range
- Guarantees the circuit even in areas with extremely high ambient temperatures
- Blast furnaces and coking plants
- Refineries
- Glassworks
- Aluminium and steelworks
Product features
- Flame-retardant
- Halogen-free
- Only suitable for installation in dry conditions
Design
- Fine-wire strand made of nickel-plated copper
- MICA tape wrapping and impregnated glass fibre braid
- Cores twisted together
- Outer sheath made of MICA tape wrapping and impregnated glass fibre braid, red
Classification
- ETIM 5.0 Class-ID: EC001578
- ETIM 5.0 Class-Description: Flexible cable
Core identification code
- 2-core cable:
blue, brown - 4-core cable:
black, blue, yellow, red
Conductor design
- Fine copper wire strands
Minimum bending radius
- Fixed installation:
5 x cable diameter
Nominal voltage
- U0/U: 300/500 V
Test voltage
- 2200 V
Temperature range
- -195°C to +400°C
- Short-term: up to +1565°C
| Article number |
Number of cores and mm² per conductor |
Outer diameter (mm) |
Copper index (kg/km) |
Weight (kg/km) |
| ÖLFLEX® HEAT 1565 MC | ||||
| 30020808 | 2 x 0.5 | 7 | 9.6 | 48 |
| 30020809 | 2 x 0.75 | 7.4 | 14.4 | 66 |
| 30016609 | 2 x 1 | 7.7 | 19.2 | 74 |
| 30016603 | 2 x 1.5 | 8.2 | 28.8 | 87 |
| 30020810 | 2 x 2.5 | 9.7 | 48 | 114 |
| 30020811 | 2 x 4 | 11.2 | 76.8 | 161 |
| 30016606 | 4 x 1 | 8.9 | 38.4 | 123 |
| 30016600 | 4 x 1.5 | 9.5 | 57.6 | 148 |
