ÖLFLEX® HEAT 125 SC

VDE-tested single cores according to EN 50525-3-41 (H05Z-K & H07Z-K) for increased application requirements

ÖLFLEX® HEAT 125 SC – highly flame-retardant single core cable with enhanced properties in the event of fire for a wide range of applications up to +125°C

  • Now available in large cardboard boxes
  • VDE-tested and -marked
  • Improved characteristics in the event of a fire

UV-resistant Temperature-resistant Assembly time Halogen-free Flame-retardant Cold-resistant

Benefits

  • For safety in areas with a high density of people
  • Reduction of flame propagation, density and toxicity of smoke gases in the event of fire
  • Minimises damage to buildings and equipment caused by the formation of toxic acid fumes in fires
  • Certified for maritime applications

Application range

  • For the wiring and connection of lighting, heating appliances, switch panels, and distributors in machine, plant and apparatus construction
  • For installation in tubes, on, in and under plaster as well as in closed installation ducts
  • Winding products, (electro)magnets, pumps, electrical systems
  • Heat treatment plants, pressure die casting, heating and cooling technology
  • Suitable for assembling cable harnesses and wiring during switch cabinet installation

Product features

  • Fire behaviour:
    – Flame-retardant (IEC 60332-1-2)
    – Halogen-free (IEC 60754-1)
    – Corrosiveness of gases (IEC 60754-2)
    – Smoke density (IEC 61034-2)
    – Low toxicity (EN 50305)
  • Enhanced fire behaviour:
    H05Z-K (0.5mm² up to 1.0mm²):
    see data sheet
    H07Z-K (≥ 1.5mm²):
    no fire propagation according to IEC 60332-3-24 and IEC 60332-3-25
  • Oil-resistant according to DIN EN 50290-2-22 (TM54)
  • Abrasion-resistant and notch-resistant
  • UV-resistant according to ISO 4892-2

Norm references / approvals

  • Type H05Z-K and H07Z-K according to EN 50525-3-41 with enhanced features
  • Germanischer Lloyd (GL)
    certificate no. 11118-14HH

Design

  • Fine-wire, tin-plated copper conductor
  • Electron beam cross-linked polyolefin copolymer insulation

Classification

  • ETIM 5.0 Class-ID: EC000993
  • ETIM 5.0 Class-Description: Single-core cable

Conductor design

  • Fine wire according to VDE 0295, class 5 / IEC 60228 class 5 from 0.5 mm²

Minimum bending radius

  • Fixed installation: 4 x outer diameter

Nominal voltage

  • Up to 1.0mm² U0/U 300/500 V
    From 1.5mm² U0/U 450/750 V
  • 0.6/1kV from 1.5 mm² in the case of fixed and protected installation

Test voltage

  • 4000 V

Temperature range

  • Fixed installation: -55°C to +125°C
    Temporary (3,000 h): up to +145°C
Article number Conductor cross-section
(mm²)		 Outer diameter [mm]
(mm)		 Core colour
(kg/km)		 m/ring
(kg/km)		 Copper index (kg/km) Weight (kg/km)
ÖLFLEX® HEAT 125 SC – H05Z-K – U0/U: 300/500 V
1232000 0.5 2.2 green/yellow 100 4.8 8
1232001 0.5 2.2 black 100 4.8 8
1232002 0.5 2.2 blue 100 4.8 8
1232003 0.5 2.2 brown 100 4.8 8
1232005 0.5 2.2 yellow 100 4.8 8
1232006 0.5 2.2 green 100 4.8 8
1232007 0.5 2.2 violet 100 4.8 8
1232009 0.5 2.2 orange 100 4.8 8
1232104 0.5 2.2 red 100 4.8 8
1232105 0.5 2.2 white 100 4.8 8
1232106 0.5 2.2 grey 100 4.8 8
1232114 0.5 2.2 dark blue 100 4.8 8
1232001K 0.5 2.2 black 3000 4.8 8
1233000 0.75 2.4 green/yellow 100 7.2 11
1233001 0.75 2.4 black 100 7.2 11
1233002 0.75 2.4 blue 100 7.2 11
1233003 0.75 2.4 brown 100 7.2 11
1233005 0.75 2.4 yellow 100 7.2 11
1233006 0.75 2.4 green 100 7.2 11
1233007 0.75 2.4 violet 100 7.2 11
1233009 0.75 2.4 orange 100 7.2 11
1233104 0.75 2.4 red 100 7.2 11
1233105 0.75 2.4 white 100 7.2 11
1233106 0.75 2.4 grey 100 7.2 11
1233114 0.75 2.4 dark blue 100 7.2 11
1233003K 0.75 2.4 brown 2500 7.2 11
1233001K 0.75 2.4 black 2500 7.2 11
1233106K 0.75 2.4 grey 2500 7.2 11
1233002K 0.75 2.4 blue 2500 7.2 11
1233009K 0.75 2.4 orange 2500 7.2 11
1233114K 0.75 2.4 dark blue 2500 7.2 11
1233105K 0.75 2.4 white 2500 7.2 11
1233104K 0.75 2.4 red 2500 7.2 11
1234000 1 2.5 green/yellow 100 9.6 14
1234001 1 2.5 black 100 9.6 14
1234002 1 2.5 blue 100 9.6 14
1234003 1 2.5 brown 100 9.6 14
1234005 1 2.5 yellow 100 9.6 14
1234006 1 2.5 green 100 9.6 14
1234007 1 2.5 violet 100 9.6 14
1234009 1 2.5 orange 100 9.6 14
1234104 1 2.5 red 100 9.6 14
1234105 1 2.5 white 100 9.6 14
1234106 1 2.5 grey 100 9.6 14
1234114 1 2.5 dark blue 100 9.6 14
1234003K 1 2.5 brown 2500 9.6 14
1234001K 1 2.5 black 2500 9.6 14
1234106K 1 2.5 grey 2500 9.6 14
1234002K 1 2.5 blue 2500 9.6 14
1234000K 1 2.5 green/yellow 2500 9.6 14
1234009K 1 2.5 orange 2500 9.6 14
1234114K 1 2.5 dark blue 2500 9.6 14
1234105K 1 2.5 white 2500 9.6 14
1234104K 1 2.5 red 2500 9.6 14
ÖLFLEX® HEAT 125 SC – H07Z-K – U0/U: 450/750 V
1235000 1.5 3 green/yellow 100 14.4 21
1235001 1.5 3 black 100 14.4 21
1235002 1.5 3 blue 100 14.4 21
1235003 1.5 3 brown 100 14.4 21
1235005 1.5 3 yellow 100 14.4 21
1235006 1.5 3 green 100 14.4 21
1235007 1.5 3 violet 100 14.4 21
1235009 1.5 3 orange 100 14.4 21
1235104 1.5 3 red 100 14.4 21
1235105 1.5 3 white 100 14.4 21
1235106 1.5 3 grey 100 14.4 21
1235114 1.5 3 dark blue 100 14.4 21
1235003K 1.5 3 brown 2000 14.4 21
1235001K 1.5 3 black 2000 14.4 21
1235106K 1.5 3 grey 2000 14.4 21
1235002K 1.5 3 blue 2000 14.4 21
1235000K 1.5 3 green/yellow 2000 14.4 21
1235009K 1.5 3 orange 2000 14.4 21
1235114K 1.5 3 dark blue 2000 14.4 21
1235105K 1.5 3 white 2000 14.4 21
1235104K 1.5 3 red 2000 14.4 21
1236000 2.5 3.6 green/yellow 100 24 33
1236001 2.5 3.6 black 100 24 33
1236002 2.5 3.6 blue 100 24 33
1236003 2.5 3.6 brown 100 24 33
1236005 2.5 3.6 yellow 100 24 33
1236006 2.5 3.6 green 100 24 33
1236007 2.5 3.6 violet 100 24 33
1236009 2.5 3.6 orange 100 24 33
1236104 2.5 3.6 red 100 24 33
1236105 2.5 3.6 white 100 24 33
1236106 2.5 3.6 grey 100 24 33
1236114 2.5 3.6 dark blue 100 24 33
1236001K 2.5 3.6 black 1200 24 33
1237000 4 4.3 green/yellow 100 38.4 49
1237001 4 4.3 black 100 38.4 49
1237002 4 4.3 blue 100 38.4 49
1237003 4 4.3 brown 100 38.4 49
1237009 4 4.3 orange 100 38.4 49
1237104 4 4.3 red 100 38.4 49
1237105 4 4.3 white 100 38.4 49
1237106 4 4.3 grey 100 38.4 49
1237114 4 4.3 dark blue 100 38.4 49
1238000 6 4.8 green/yellow 100 57.6 67
1238001 6 4.8 black 100 57.6 67
1238002 6 4.8 blue 100 57.6 67
1238003 6 4.8 brown 100 57.6 67
1238104 6 4.8 red 100 57.6 67
1238106 6 4.8 grey 100 57.6 67
1238114 6 4.8 dark blue 100 57.6 67
1239000 10 6.2 green/yellow 100 96 112
1239001 10 6.2 black 100 96 112
1239002 10 6.2 blue 100 96 112
1239003 10 6.2 brown 100 96 112
1239104 10 6.2 red 100 96 112
1240000 16 7.2 green/yellow 100 153.6 172
1240001 16 7.2 black 100 153.6 172
1240002 16 7.2 blue 100 153.6 172
1240003 16 7.2 brown 100 153.6 172
1240104 16 7.2 red 100 153.6 172
1240114 16 7.2 dark blue 100 153.6 172
1241000 25 8.9 green/yellow 100 240 262
1241001 25 8.9 black 100 240 262
1242000 35 10.1 green/yellow 100 336 362
1242001 35 10.1 black 100 336 362
1243000 50 12.5 green/yellow 100 480 512
1243001 50 12.5 black 100 480 512
1244000 70 14.2 green/yellow 100 672 710
1244001 70 14.2 black 100 672 710
1245000 95 16.6 green/yellow 100 912 937
1245001 95 16.6 black 100 912 937
1246001 120 18.2 black 100 1152 1159
1247000 150 20.6 green/yellow 100 1440 1447
1247001 150 20.6 black 100 1440 1447
1248001 185 22.5 black 100 1776 1790
1249001 240 26.4 black 100 2304 2318
