ÖLFLEX® HEAT 180 SiF

Versatile braided conductor with wide temperature range

ÖLFLEX® HEAT 180 SiF – silicone single core cable for use in machine, plant and apparatus construction and for increased temperature requirements up to +180°C

Flexible fine-wire copper conductor

Temperature-resistant Halogen-free Cold-resistant

Benefits

  • The remaining SiO2 ash has insulating properties after combustion

Application range

  • Areas with high ambient temperatures where conventional core insulation materials will become brittle after a short period
  • Typical fields of application
    – Control cabinet manufacturing
    – Appliances and apparatus engineering
    – Electric motor industry
    – Sauna/solarium construction
    – Thermal and heating elements
    – Lighting technology
    – Ventilator engineering
    – Air-conditioning technology
    – Furnace construction
    – Plastic processing
    – Generator and transformer manufacturing

Product features

  • Halogen-free according to IEC 60754-1
    (amount of halogen acidic gas)
    Corrosiveness of combustion gases according to IEC 60754-2 (degree of acidity)
  • Flame-retardant according to IEC 60332-1-2
  • Resistant to a multitude of oils, alcohols, vegetable and animal fats and chemical substances
  • Adequate ventilation must be ensured, since the mechanical properties of silicone cables prematurely decrease from +100°C in the absence of air

Design

  • Fine-wire, tin-plated copper conductor
  • Silicone-based insulation

Classification

  • ETIM 5.0 Class-ID: EC000993
  • ETIM 5.0 Class-Description: Single-core cable

Conductor design

  • Fine wire according to VDE 0295, class 5 / IEC 60228 class 5 from 0.5 mm²

Minimum bending radius

  • Fixed installation: 6 x outer diameter
    Single bend: 3 x cable diameter

Nominal voltage

  • U0/U: 300/500 V

Test voltage

  • 2000 V

Temperature range

  • -50°C to +180°C
    (adequate ventilation required)
  • Short-term: +200°C
Article number Conductor cross-section
(mm²)		 Outer diameter [mm] Core colour Copper index (kg/km) Weight (kg/km)
ÖLFLEX® HEAT 180 SiF
0047000 0.25 1.9 green/yellow 2.4 5.4
0047001 0.25 1.9 black 2.4 5.4
0047002 0.25 1.9 blue 2.4 5.4
0047003 0.25 1.9 brown 2.4 5.4
0047005 0.25 1.9 yellow 2.4 5.4
0047006 0.25 1.9 green 2.4 5.4
0047007 0.25 1.9 violet 2.4 5.4
0047008 0.25 1.9 pink 2.4 5.4
0047009 0.25 1.9 orange 2.4 5.4
0047104 0.25 1.9 red 2.4 5.4
0047105 0.25 1.9 white 2.4 5.4
0047106 0.25 1.9 grey 2.4 5.4
0048000 0.5 2.1 green/yellow 4.8 9
0048001 0.5 2.1 black 4.8 9
0048002 0.5 2.1 blue 4.8 9
0048003 0.5 2.1 brown 4.8 9
0048005 0.5 2.1 yellow 4.8 9
0048006 0.5 2.1 green 4.8 9
0048007 0.5 2.1 violet 4.8 9
0048008 0.5 2.1 pink 4.8 9
0048009 0.5 2.1 orange 4.8 9
0048104 0.5 2.1 red 4.8 9
0048105 0.5 2.1 white 4.8 9
0048106 0.5 2.1 grey 4.8 9
0049000 0.75 2.4 green/yellow 7.2 12
0049001 0.75 2.4 black 7.2 12
0049002 0.75 2.4 blue 7.2 12
0049003 0.75 2.4 brown 7.2 12
0049005 0.75 2.4 yellow 7.2 12
0049006 0.75 2.4 green 7.2 12
0049007 0.75 2.4 violet 7.2 12
0049008 0.75 2.4 pink 7.2 12
0049009 0.75 2.4 orange 7.2 12
0049104 0.75 2.4 red 7.2 12
0049105 0.75 2.4 white 7.2 12
0049106 0.75 2.4 grey 7.2 12
0050000 1 2.5 green/yellow 9.6 15
0050001 1 2.5 black 9.6 15
0050002 1 2.5 blue 9.6 15
0050003 1 2.5 brown 9.6 15
0050005 1 2.5 yellow 9.6 15
0050006 1 2.5 green 9.6 15
0050007 1 2.5 violet 9.6 15
0050008 1 2.5 pink 9.6 15
0050009 1 2.5 orange 9.6 15
0050104 1 2.5 red 9.6 15
0050105 1 2.5 white 9.6 15
0050106 1 2.5 grey 9.6 15
0051000 1.5 2.8 green/yellow 14.4 20
0051001 1.5 2.8 black 14.4 20
0051002 1.5 2.8 blue 14.4 20
0051003 1.5 2.8 brown 14.4 20
0051005 1.5 2.8 yellow 14.4 20
0051006 1.5 2.8 green 14.4 20
0051007 1.5 2.8 violet 14.4 20
0051008 1.5 2.8 pink 14.4 20
0051009 1.5 2.8 orange 14.4 20
0051104 1.5 2.8 red 14.4 20
0051105 1.5 2.8 white 14.4 20
0051106 1.5 2.8 grey 14.4 20
0052000 2.5 3.4 green/yellow 24 32
0052001 2.5 3.4 black 24 32
0052002 2.5 3.4 blue 24 32
0052003 2.5 3.4 brown 24 32
0052005 2.5 3.4 yellow 24 32
0052006 2.5 3.4 green 24 32
0052007 2.5 3.4 violet 24 32
0052104 2.5 3.4 red 24 32
0052105 2.5 3.4 white 24 32
0052106 2.5 3.4 grey 24 32
0053000 4 4.2 green/yellow 38 50
0053001 4 4.2 black 38 50
0053002 4 4.2 blue 38 50
0053003 4 4.2 brown 38 50
0053005 4 4.2 yellow 38 50
0053006 4 4.2 green 38 50
0053009 4 4.2 orange 38 50
0053104 4 4.2 red 38 50
0053105 4 4.2 white 38 50
0053106 4 4.2 grey 38 50
0054000 6 5 green/yellow 58 73
0054001 6 5 black 58 73
0054002 6 5 blue 58 73
0054003 6 5 brown 58 73
0054005 6 5 yellow 58 73
0054006 6 5 green 58 73
0054104 6 5 red 58 73
0054105 6 5 white 58 73
0054106 6 5 grey 58 73
0055000 10 6.6 green/yellow 96 118
0055001 10 6.6 black 96 118
0055002 10 6.6 blue 96 118
0055003 10 6.6 brown 96 118
0055009 10 6.6 orange 96 118
0055104 10 6.6 red 96 118
0055105 10 6.6 white 96 118
0055106 10 6.6 grey 96 118
0056000 16 7.4 green/yellow 154 177
0056001 16 7.4 black 154 177
0056002 16 7.4 blue 154 177
0056104 16 7.4 red 154 177
0056105 16 7.4 white 154 177
0056106 16 7.4 grey 154 177
0057000 25 9.2 green/yellow 240 277
0057001 25 9.2 black 240 277
0057002 25 9.2 blue 240 277
0057104 25 9.2 red 240 277
0057106 25 9.2 grey 240 277
0058000 35 10.3 green/yellow 336 374
0058001 35 10.3 black 336 374
0058002 35 10.3 blue 336 374
0058104 35 10.3 red 336 374
0059000 50 12.2 green/yellow 480 530
0059001 50 12.2 black 480 530
0059104 50 12.2 red 480 530
0060001 70 14.2 black 672 724
0060002 70 14.2 blue 672 724
0061000 95 16.6 green/yellow 912 982
0061001 95 16.6 black 912 982
0061105 95 16.6 white 912 982
0062000 120 18 green/yellow 1152 1219
0062001 120 18 black 1152 1219
0063001 150 20 black 1440 1524
0064001 185 22.5 black 1776 1915
