Benefits

• The remaining SiO2 ash has insulating properties after combustion

Application range

• Areas with high ambient temperatures where conventional core insulation materials will become brittle after a short period
• Typical fields of application
  – Control cabinet manufacturing
  – Appliances and apparatus engineering
  – Electric motor industry
  – Sauna/solarium construction
  – Thermal and heating elements
  – Lighting technology
  – Ventilator engineering
  – Air-conditioning technology
  – Furnace construction
  – Plastic processing
  – Generator and transformer manufacturing
• ÖLFLEX^®
  HEAT 180 SiZ is used as a temperature sensor pair for solar ducts for solar thermal systems

Product features

• Halogen-free according to IEC 60754-1
  (amount of halogen acidic gas)
  Corrosiveness of combustion gases according to IEC 60754-2 (degree of acidity)
• Flame-retardant according to IEC 60332-1-2
• Resistant to a multitude of oils, alcohols, vegetable and animal fats and chemical substances
• Adequate ventilation must be ensured, since the mechanical properties of silicone cables prematurely decrease from +100°C in the absence of air

Design

• Fine-wire, tin-plated copper conductor
• Silicone-based insulation
• Core colour: Red
• Cores connected in parallel with a separating strip
• One of the two cores is marked for identification
