ÖLFLEX® HEAT 205 SC

For very high and low temperature requirements

ÖLFLEX® HEAT 205 SC – FEP single core cable, robust, chemical-resistant and space-saving for use in machine and apparatus construction at temperatures -100°C to +205°C

  • Now available as spools
  • Thermal and chemical resistance
  • Space and weight-saving

UV-resistant Temperature-resistant Acid-resistant Oil-resistant Low weight Good chemical resistance Flame-retardant Cold-resistant

Benefits

  • Small outer diameters for maximum saving of space and weight
  • Resistant to most highly aggressive chemical media

Application range

  • Conventional cables cannot be used in industrial environments with very high temperatures, aggressive chemical media and limited space
  • Typical fields of application
    – Control cabinets with high heat
    generation
    – Measuring instruments
    – Furnaces and brickworks
    – Heating equipment and kitchen
    appliances
    – Electric motor building
    – Installations in the chemical industry

Product features

  • Flame-retardant according to IEC 60332-1-2
  • ÖLFLEX® HEAT 205 made of FEP
    – Outstanding resistance against acids,
    solvents, lacquers, petrol, oils
    and many other chemical media
    – Flame-retardant
    – High dielectric strength and
    abrasion-resistance
    – Low water absorption
    – Resistant to microbes
    – Adhesion-free insulation materials
    – Weather- and ozone-resistant
    – Hydrophobic and dirt-repellent
    – High elongation capacity and tear
    resistance
    – Resistant against hydraulic fluids

Design

  • Fine-wire, tin-plated copper conductor
  • FEP core insulation
  • FEP = fluorinated ethylene propylene

Classification

  • ETIM 5.0 Class-ID: EC000993
  • ETIM 5.0 Class-Description: Single-core cable

Conductor design

  • Fine wire according to VDE 0295, class 5 / IEC 60228 class 5 from 0.5 mm²

Minimum bending radius

  • Fixed installation: 4 x outer diameter

Nominal voltage

  • U0/U: 300/500 V

Test voltage

  • 2500 V

Temperature range

  • Fixed installation: -100°C to +205°C
Article number Conductor cross-section
(mm²)		 Outer diameter [mm] m/ring Core colour Copper index (kg/km) Weight (kg/km)
ÖLFLEX® HEAT 205 SC
0080001 0.14 1 100 black 1.35 2.6
0080002 0.14 1 100 blue 1.35 2.6
0080005 0.14 1 100 yellow 1.35 2.6
0080006 0.14 1 100 green 1.35 2.6
0080010 0.14 1 100 transparent 1.35 2.6
0080104 0.14 1 100 red 1.35 2.6
0080105 0.14 1 100 white 1.35 2.6
0081001 0.25 1.2 100 black 2.4 4
0081002 0.25 1.2 100 blue 2.4 4
0081003 0.25 1.2 100 brown 2.4 4
0081005 0.25 1.2 100 yellow 2.4 4
0081006 0.25 1.2 100 green 2.4 4
0081009 0.25 1.2 100 orange 2.4 4
0081010 0.25 1.2 100 transparent 2.4 4
0081104 0.25 1.2 100 red 2.4 4
0081105 0.25 1.2 100 white 2.4 4
0081106 0.25 1.2 100 grey 2.4 4
0081003S 0.25 1.2 500 brown 2.4 4
0081001S 0.25 1.2 500 black 2.4 4
0081002S 0.25 1.2 500 blue 2.4 4
0081104S 0.25 1.2 500 red 2.4 4
0082000 0.5 1.45 100 green/yellow 4.8 6.8
0082001 0.5 1.45 100 black 4.8 6.8
0082002 0.5 1.45 100 blue 4.8 6.8
0082003 0.5 1.45 100 brown 4.8 6.8
0082005 0.5 1.45 100 yellow 4.8 6.8
0082006 0.5 1.45 100 green 4.8 6.8
0082007 0.5 1.45 100 violet 4.8 6.8
0082009 0.5 1.45 100 orange 4.8 6.8
0082010 0.5 1.45 100 transparent 4.8 6.8
0082104 0.5 1.45 100 red 4.8 6.8
0082105 0.5 1.45 100 white 4.8 6.8
0082106 0.5 1.45 100 grey 4.8 6.8
0082003S 0.5 1.45 500 brown 4.8 6.8
0082001S 0.5 1.45 500 black 4.8 6.8
0082002S 0.5 1.45 500 blue 4.8 6.8
0082104S 0.5 1.45 500 red 4.8 6.8
0083000 0.75 1.8 100 green/yellow 7.2 10.1
0083001 0.75 1.8 100 black 7.2 10.1
0083002 0.75 1.8 100 blue 7.2 10.1
0083003 0.75 1.8 100 brown 7.2 10.1
0083005 0.75 1.8 100 yellow 7.2 10.1
0083006 0.75 1.8 100 green 7.2 10.1
0083010 0.75 1.8 100 transparent 7.2 10.1
0083104 0.75 1.8 100 red 7.2 10.1
0083105 0.75 1.8 100 white 7.2 10.1
0083003S 0.75 1.8 500 brown 7.2 10.1
0083001S 0.75 1.8 500 black 7.2 10.1
0083002S 0.75 1.8 500 blue 7.2 10.1
0083000S 0.75 1.8 500 green/yellow 7.2 10.1
0083104S 0.75 1.8 500 red 7.2 10.1
0084000 1 1.95 100 green/yellow 9.6 12.8
0084001 1 1.95 100 black 9.6 12.8
0084002 1 1.95 100 blue 9.6 12.8
0084003 1 1.95 100 brown 9.6 12.8
0084005 1 1.95 100 yellow 9.6 12.8
0084006 1 1.95 100 green 9.6 12.8
0084007 1 1.95 100 violet 9.6 12.8
0084010 1 1.95 100 transparent 9.6 12.8
0084104 1 1.95 100 red 9.6 12.8
0084105 1 1.95 100 white 9.6 12.8
0084106 1 1.95 100 grey 9.6 12.8
0084003S 1 1.95 500 brown 9.6 12.8
0084001S 1 1.95 500 black 9.6 12.8
0084002S 1 1.95 500 blue 9.6 12.8
0084000S 1 1.95 500 green/yellow 9.6 12.8
0084104S 1 1.95 500 red 9.6 12.8
0085000 1.5 2.1 100 green/yellow 14.4 18
0085001 1.5 2.1 100 black 14.4 18
0085002 1.5 2.1 100 blue 14.4 18
0085003 1.5 2.1 100 brown 14.4 18
0085005 1.5 2.1 100 yellow 14.4 18
0085010 1.5 2.1 100 transparent 14.4 18
0085104 1.5 2.1 100 red 14.4 18
0085105 1.5 2.1 100 white 14.4 18
0085003S 1.5 2.1 500 brown 14.4 18
0085001S 1.5 2.1 500 black 14.4 18
0085002S 1.5 2.1 500 blue 14.4 18
0085000S 1.5 2.1 500 green/yellow 14.4 18
0085104S 1.5 2.1 500 red 14.4 18
0086000 2.5 2.6 100 green/yellow 24 29.5
0086001 2.5 2.6 100 black 24 29.5
0086002 2.5 2.6 100 blue 24 29.5
0086003 2.5 2.6 100 brown 24 29.5
0086007 2.5 2.6 100 violet 24 29.5
0086010 2.5 2.6 100 transparent 24 29.5
0086104 2.5 2.6 100 red 24 29.5
0086105 2.5 2.6 100 white 24 29.5
0086106 2.5 2.6 100 grey 24 29.5
0086003S 2.5 2.6 500 brown 24 29.5
0086001S 2.5 2.6 500 black 24 29.5
0086002S 2.5 2.6 500 blue 24 29.5
0086000S 2.5 2.6 500 green/yellow 24 29.5
0086104S 2.5 2.6 500 red 24 29.5
0087000 4 3.1 100 green/yellow 38 45
0087001 4 3.1 100 black 38 45
0087002 4 3.1 100 blue 38 45
0087003 4 3.1 100 brown 38 45
0087005 4 3.1 100 yellow 38 45
0087010 4 3.1 100 transparent 38 45
0087104 4 3.1 100 red 38 45
0087105 4 3.1 100 white 38 45
0088000 6 3.8   green/yellow 58 68
0088001 6 3.8   black 58 68
0088002 6 3.8   blue 58 68
0088003 6 3.8   brown 58 68
0088010 6 3.8   transparent 58 68
0088104 6 3.8   red 58 68
0089000 10 4.7   green/yellow 96 116
0089001 10 4.7   black 96 116
0089002 10 4.7   blue 96 116
0089003 10 4.7   brown 96 116
0089010 10 4.7   transparent 96 116
0089104 10 4.7   red 96 116
0089105 10 4.7   white 96 116
0089106 10 4.7   grey 96 116
0090000 16 6.6   green/yellow 154 175
0090001 16 6.6   black 154 175
0090002 16 6.6   blue 154 175
0090104 16 6.6   red 154 175
