ÖLFLEX® HEAT 260 SC

For the most extreme application requirements

ÖLFLEX® HEAT 260 SC – PTFE single core cable, robust, chemical-resistant and space-saving for use in machine and apparatus construction at temperatures -190°C to +260°C

  • Excellent chemical, thermal and electrical properties
  • Space and weight-saving

UV-resistant Temperature-resistant Acid-resistant Oil-resistant Low weight Good chemical resistance Flame-retardant Cold-resistant

Benefits

  • Small outer diameters for maximum saving of space and weight
  • Resistant to most highly aggressive chemical media
  • Stress crack resistant in case of frequent ambient temperature fluctuations

Application range

  • Conventional cables cannot be used in industrial environments with very high temperatures, aggressive chemical media and limited space
  • Typical fields of application
    – Aerospace engineering
    – High-frequency engineering
    – Control cabinets with high heat
    generation
    – Measuring instruments
    – Furnaces and brickworks
    – Heating equipment and kitchen
    appliances
    – Electric motor construction
    – Installations in the chemical industry

Product features

  • Flame-retardant according to IEC 60332-1-2
  • ÖLFLEX® HEAT 260 made of PTFE
    – Outstanding resistance against acids,
    alkalis, solvents, lacquers, petrol, oils
    and many other chemical media
    – Flame-retardant
    – High dielectric strength and
    abrasion-resistance
    – Low water absorption
    – Resistant to microbes
    – Adhesion-free insulation materials
    – Weather- and ozone-resistant
    – Hydrophobic and dirt-repellent
    – High elongation capacity and tear
    resistance
    – Withstands contact with liquid nitrogen
    – Resistant against hydraulic fluids
  • Silver-plated copper wire is characterised by good surface conductivity (skin effect) and good solderability

Design

  • AWG conductor made of silver-plated copper wires
  • PTFE core insulation
  • PTFE = Polytetrafluoroethylene

Classification

  • ETIM 5.0 Class-ID: EC000993
  • ETIM 5.0 Class-Description: Single-core cable

Conductor design

  • AWG conductor sizes: 7, 19 or 37 wires

Minimum bending radius

  • Fixed installation: 4 x outer diameter

Nominal voltage

  • U0/U: 300/500 V

Test voltage

  • 3400 V

Temperature range

  • Fixed installation: -190°C to +260°C
Article number AWG no. and wire number Outer diameter [mm] Core colour Copper index (kg/km) Weight (kg/km)
ÖLFLEX® HEAT 260 SC
0094000 28 (7) 0.89 green/yellow 0.9 2
0094001 28 (7) 0.89 black 0.9 2
0094002 28 (7) 0.89 blue 0.9 2
0094003 28 (7) 0.89 brown 0.9 2
0094005 28 (7) 0.89 yellow 0.9 2
0094006 28 (7) 0.89 green 0.9 2
0094007 28 (7) 0.89 violet 0.9 2
0094009 28 (7) 0.89 orange 0.9 2
0094104 28 (7) 0.89 red 0.9 2
0094105 28 (7) 0.89 white 0.9 2
0094106 28 (7) 0.89 grey 0.9 2
0095001 26 (7) 0.99 black 1.4 2.7
0095002 26 (7) 0.99 blue 1.4 2.7
0095006 26 (7) 0.99 green 1.4 2.7
0095007 26 (7) 0.99 violet 1.4 2.7
0095009 26 (7) 0.99 orange 1.4 2.7
0095104 26 (7) 0.99 red 1.4 2.7
0095105 26 (7) 0.99 white 1.4 2.7
0095106 26 (7) 0.99 grey 1.4 2.7
0096000 26 (19) 0.99 green/yellow 1.5 2.9
0096001 26 (19) 0.99 black 1.5 2.9
0096006 26 (19) 0.99 green 1.5 2.9
00106011 26 (19) 0.99 grey 1.5 2.9
0096104 26 (19) 0.99 red 1.5 2.9
0097001 24 (7) 1.12 black 2.2 3.8
0097002 24 (7) 1.12 blue 2.2 3.8
0097003 24 (7) 1.12 brown 2.2 3.8
0097104 24 (7) 1.12 red 2.2 3.8
0097105 24 (7) 1.12 white 2.2 3.8
0098000 24 (19) 1.12 green/yellow 2.3 4
0098001 24 (19) 1.12 black 2.3 4
0098002 24 (19) 1.12 blue 2.3 4
0098003 24 (19) 1.12 brown 2.3 4
0098006 24 (19) 1.12 green 2.3 4
0098104 24 (19) 1.12 red 2.3 4
0098105 24 (19) 1.12 white 2.3 4
0098106 24 (19) 1.12 grey 2.3 4
0099001 22 (7) 1.27 black 3.4 5.4
0099002 22 (7) 1.27 blue 3.4 5.4
0099003 22 (7) 1.27 brown 3.4 5.4
0099005 22 (7) 1.27 yellow 3.4 5.4
0099006 22 (7) 1.27 green 3.4 5.4
0099007 22 (7) 1.27 violet 3.4 5.4
0099104 22 (7) 1.27 red 3.4 5.4
0099105 22 (7) 1.27 white 3.4 5.4
0100001 22 (19) 1.27 black 3.7 5.7
0100002 22 (19) 1.27 blue 3.7 5.7
0100003 22 (19) 1.27 brown 3.7 5.7
0100005 22 (19) 1.27 yellow 3.7 5.7
0100009 22 (19) 1.27 orange 3.7 5.7
0100104 22 (19) 1.27 red 3.7 5.7
0100105 22 (19) 1.27 white 3.7 5.7
0101001 20 (7) 1.47 black 5.4 7.7
0101002 20 (7) 1.47 blue 5.4 7.7
0101003 20 (7) 1.47 brown 5.4 7.7
0101006 20 (7) 1.47 green 5.4 7.7
0101104 20 (7) 1.47 red 5.4 7.7
0101105 20 (7) 1.47 white 5.4 7.7
0102001 20 (19) 1.47 black 5.9 8.2
0102002 20 (19) 1.47 blue 5.9 8.2
0102003 20 (19) 1.47 brown 5.9 8.2
0102005 20 (19) 1.47 yellow 5.9 8.2
0102006 20 (19) 1.47 green 5.9 8.2
0102007 20 (19) 1.47 violet 5.9 8.2
0102009 20 (19) 1.47 orange 5.9 8.2
0102104 20 (19) 1.47 red 5.9 8.2
0102105 20 (19) 1.47 white 5.9 8.2
0102106 20 (19) 1.47 grey 5.9 8.2
0103001 18 (7) 1.74 black 8.6 12
0102000 20 (19) 1.47 green/yellow 5.9 8.2
0103104 18 (7) 1.74 red 8.6 12
0104000 18 (19) 1.74 green/yellow 9.3 12
0104001 18 (19) 1.74 black 9.3 12
0104002 18 (19) 1.74 blue 9.3 12
0104003 18 (19) 1.74 brown 9.3 12
0104005 18 (19) 1.74 yellow 9.3 12
0104006 18 (19) 1.74 green 9.3 12
0104007 18 (19) 1.74 violet 9.3 12
0104009 18 (19) 1.74 orange 9.3 12
0104104 18 (19) 1.74 red 9.3 12
0104105 18 (19) 1.74 white 9.3 12
0105000 16 (19) 2.04 green/yellow 11.8 16
0105001 16 (19) 2.04 black 11.8 16
0105002 16 (19) 2.04 blue 11.8 16
0105003 16 (19) 2.04 brown 11.8 16
0105005 16 (19) 2.04 yellow 11.8 16
0105006 16 (19) 2.04 green 11.8 16
0105007 16 (19) 2.04 violet 11.8 16
0105009 16 (19) 2.04 orange 11.8 16
0105104 16 (19) 2.04 red 11.8 16
0105105 16 (19) 2.04 white 11.8 16
0106000 14 (19) 2.42 green/yellow 18.7 23
0106001 14 (19) 2.42 black 18.7 23
0106002 14 (19) 2.42 blue 18.7 23
0106003 14 (19) 2.42 brown 18.7 23
0106005 14 (19) 2.42 yellow 18.7 23
0106006 14 (19) 2.42 green 18.7 23
0106104 14 (19) 2.42 red 18.7 23
0106105 14 (19) 2.42 white 18.7 23
0106106 14 (19) 2.42 grey 18.7 23
0107000 12 (19) 2.87 green/yellow 29.6 35
0107001 12 (19) 2.87 black 29.6 35
0107002 12 (19) 2.87 blue 29.6 35
0107003 12 (19) 2.87 brown 29.6 35
0107005 12 (19) 2.87 yellow 29.6 35
0107006 12 (19) 2.87 green 29.6 35
0107009 12 (19) 2.87 orange 29.6 35
0107105 12 (19) 2.87 white 29.6 35
0108000 10 (37) 3.4 green/yellow 45.6 51
0108001 10 (37) 3.4 black 45.6 51
0108002 10 (37) 3.4 blue 45.6 51
0108104 10 (37) 3.4 red 45.6 51
0108105 10 (37) 3.4 white 45.6 51

■ Similar products
▯ ÖLFLEX® HEAT 205 SC

■ Accessories
▯ UNIVERSAL STRIP stripping and cutting tool
▯ KT 11 cable shears
