ÖLFLEX® HEAT 350 SC
Suitable for use in ambient temperatures from -50°C to +350°C
ÖLFLEX® HEAT 350 SC – glass fibre single core cable for use in blast furnace, power plant, motor, apparatus and luminaire construction at temperatures up to +350°C
- For use in dry conditions
- For use in dry conditions
Benefits
- Low conductor resistance due to the nickel-plated copper conductors
Application range
- Wide operating temperature range allows versatile use in applications in thermal class C (>180°C)
- Blast furnaces and glassworks
- Chemical and power station construction
- Motor and furnace construction
- Lighting, apparatus and instrument construction
Product features
- Flame-retardant
- Halogen-free
- Only suitable for installation in dry conditions
- ÖLFLEX® HEAT 650 SC and ÖLFLEX® HEAT 1565 SC are recommended if the peak temperatures of the application are over +350°C
Design
- Fine-wire strand made of nickel-plated copper
- Core insulation made of glass fibre covering and impregnated glass fibre braid
- Core insulation from 16 mm²:
Mica wrapping and impregnated glass fibre braid - Core colour: white
Classification
- ETIM 5.0 Class-ID: EC000993
- ETIM 5.0 Class-Description: Single-core cable
Conductor design
- Fine wire according to VDE 0295 class 5 / IEC 60228 class 5
Minimum bending radius
- Fixed installation: 5 x outer diameter
Nominal voltage
- U0/U 230/400 V
Test voltage
- 1500 V
Temperature range
- Fixed installation: -50°C to +350°C
| Article number | Conductor cross-section (mm²) | Outer diameter [mm] | Copper index (kg/km) | Weight (kg/km) |
| ÖLFLEX® HEAT 350 SC | ||||
| 0091350 | 0.5 | 2.5 | 4.8 | 13 |
| 0091351 | 0.75 | 3 | 7.2 | 15 |
| 0091352 | 1 | 3.4 | 9.6 | 17 |
| 0091353 | 1.5 | 3.5 | 14.4 | 23 |
| 0091354 | 2.5 | 3.7 | 24 | 34 |
| 0091355 | 4 | 4.2 | 38.4 | 54 |
| 0091356 | 6 | 6.2 | 57.6 | 84 |
| 0091357 | 10 | 7.3 | 96 | 120 |
| 0091358 | 16 | 8 | 153.6 | 199 |
| 0091359 | 25 | 9.5 | 240 | 300 |
| 0091360 | 35 | 10.9 | 336 | 399 |
| 0091361 | 50 | 13.2 | 480 | 540 |
