ÖLFLEX® HEAT 650 SC
Suitable for use in ambient temperatures from -50°C to +700°C
ÖLFLEX® HEAT 650 SC – glass fibre single core cable for use in blast furnace, power plant, motor, apparatus and luminaire construction at temperatures up to +650°C
- For use in dry conditions
- For use in dry conditions
Benefits
- Suitable for areas where the installation temperature and ambient temperature are very high
- Good electrical conductivity due to nickel strand, even at high temperatures
Application range
- Heating modules, electric heating devices, heat cabinets
- Ovens, electric stoves, night storage heaters
- Iron and steel works, foundries, glass and ceramic processing, chemical industry
- Machinery, apparatus and power plant construction
Product features
- Flame-retardant
- Halogen-free
- Only suitable for installation in dry conditions
- ÖLFLEX® HEAT 1565 SC is recommended if the peak temperature of the application may briefly go beyond 700°C
Design
- Strand made of nickel
- Core insulation made of glass fibre covering and impregnated glass fibre braid
Classification
- ETIM 5.0 Class-ID: EC000993
- ETIM 5.0 Class-Description: Single-core cable
Conductor design
- Fine wire
- see data sheet
Minimum bending radius
- Fixed installation: 5 x outer diameter
Nominal voltage
- U0/U: 300/500 V
Test voltage
- 1800 V
Temperature range
- Occasional flexing: -50°C to +650°C
- Fixed installation: -50°C to +700°C
| Article number | Conductor cross-section (mm²) | Outer diameter [mm] | Ni-index (kg/km) | Weight (kg/km) |
| ÖLFLEX® HEAT 350 SC | ||||
| 1232650 | 0.5 | 2.4 | 4.8 | 13 |
| 1232651 | 0.75 | 2.5 | 7.6 | 15 |
| 1232652 | 1 | 2.7 | 9.7 | 17 |
| 1232653 | 1.5 | 3 | 14.8 | 23 |
| 1232654 | 2.5 | 3.5 | 23.5 | 34 |
| 1232655 | 4 | 3.9 | 38.6 | 54 |
| 1232656 | 6 | 4.6 | 57.9 | 84 |
| 1232657 | 10 | 6.8 | 96.5 | 120 |
| 1232658 | 16 | 7.5 | 152 | 199 |
| 1232659 | 25 | 9 | 236.4 | 300 |
| 1232660 | 35 | 10.4 | 332.8 | 399 |
| 1232661 | 50 | 12.7 | 481.1 | 540 |
