ÖLFLEX® HEAT 1565 SC
Suitable for use in ambient temperatures between -195°C and +400°C
ÖLFLEX® HEAT 1565 SC – glass fibre single core cable for use in blast furnace, plant and power plant construction at temperatures up to +400°C (short-term up to +1565°C)
- Short-term: up to +1565°C
- For use in dry conditions
Benefits
- Low conductor resistance due to the nickel-plated copper conductors
- Able to withstand temporary contact with molten metal or glass
Application range
- Guarantees the circuit even in areas with extremely high ambient temperatures
- Blast furnaces and coking plants
- Refineries
- Glassworks
- Aluminium and steelworks
Product features
- Flame-retardant
- Only suitable for installation in dry conditions
Design
- Fine-wire strand made of nickel-plated copper
- Mica tape wrapping
- Impregnated glass fibre braid,
core colour: red
Classification
- ETIM 5.0 Class-ID: EC000993
- ETIM 5.0 Class-Description: Single-core cable
Conductor design
- Fine copper wire strands
Minimum bending radius
- Fixed installation: 5 x outer diameter
Nominal voltage
- U0/U: 300/500 V
Test voltage
- 2200 V
Temperature range
- -195°C to +400°C
- Short-term: up to +1565°C
| Article number | Conductor cross-section (mm²) | Outer diameter [mm] | Copper index (kg/km) | Weight (kg/km) |
| ÖLFLEX® HEAT SC 1565 | ||||
| 3020780 | 0.75 | 2.9 | 7.2 | 15.9 |
| 3020781 | 1 | 3 | 9.6 | 18.8 |
| 3013234 | 1.5 | 3.3 | 14.4 | 24.3 |
| 3020782 | 2.5 | 3.8 | 24 | 35 |
| 3018942 | 4 | 4.8 | 38.4 | 56 |
| 3020783 | 6 | 5.6 | 57.6 | 86.4 |
| 3016697 | 10 | 6.2 | 96 | 123 |
| 3016698 | 16 | 7.9 | 153.6 | 202.5 |
| 3016699 | 25 | 9.2 | 240 | 295.1 |
| 3016771 | 35 | 10.6 | 336 | 403.9 |
| 3017861 | 50 | 12.2 | 480 | 545 |
