LiY with twin colour helix insulation
Hook-up wire and telecommunication wire with coloured stripes
LIY, PVC control cable, low-voltage stranded wire for telecommunication devices and electronic assemblies, twin colour helix core insulation, flame-retardant, max. +70°C
- PVC control core
- Cost-effective
- Twin-colour helically wound PVC
Application range
- Hook-up wire for wiring of telecommunication devices and electronic components within devices
Product features
- Flame-retardant according to IEC 60332-1-2
- Coil: d1 = 18 mm; d2 = 150mm; b = 85 mm
Norm references / approvals
- Based on VDE 0812
Design
- Copper stranded wire
- PVC-based core insulation, type YI 2/TI 2 according to VDE 0207-4
- Marked with coloured stripes
Classification
- ETIM 5.0 Class-ID: EC000993
- ETIM 5.0 Class-Description: Single-core cable
Peak operating voltage
- 900 V (0.25 mm²)
Conductor design
- 0.25 mm²: ≥ 14 wires (each with 0.15 mm Ø)
Nominal voltage
- Operating voltage < 50 VAC
- UPP – peak-to-peak voltage: ≤ 250 V
Test voltage
- 2500 V (0.25 mm²)
Temperature range
- Fixed installation: -30°C to +70°C
| Article number | Conductor cross-section (mm²) |
Outer diameter [mm] | Core colour | m/spool | Copper index (kg/km) |
| 4502232S | 0.25 | 1.5 | blue/black | 250 | 2.4 |
| 4502262S | 0.25 | 1.5 | blue/white | 250 | 2.4 |
| 4502282S | 0.25 | 1.5 | brown/green | 250 | 2.4 |
| 4502292S | 0.25 | 1.5 | brown/white | 250 | 2.4 |
| 4502342S | 0.25 | 1.5 | green/white | 250 | 2.4 |
| 4502392S | 0.25 | 1.5 | orange/white | 250 | 2.4 |
| 4502442S | 0.25 | 1.5 | white/blue | 250 | 2.4 |
| 4502462S | 0.25 | 1.5 | white/red | 250 | 2.4 |
