H05V-K <VDE>
<VDE> design certification
H05V-K, VDE, power and control cable, PVC, 300/500 V, wiring of machines and control cabinets, flame-retardant, class 5/fine wire, fixed installation, ring
<VDE>
Benefits
- The <VDE> cable marking is a testing mark/ proof of the successful testing according to VDE/EN/HD/IEC standards as well as possible health and safety regulations. <VDE> is issued by the VDE testing and certification institute.
Application range
- Internal wiring of devices
- Protected installation in and on lighting
- Signal systems on and under plaster in tubes
Product features
- Flame-retardant according to IEC 60332-1-2
Norm references / approvals
- <VDE> design certification according to EN 50525-2-31/ VDE 0285-525-2-31
Design
- Fine-wired copper conductor made of bare copper wires in line with braided conductor class 5 according to IEC 60228 / VDE 0295
- PVC-based core insulation
Classification
- ETIM 5.0 Class-ID: EC000993
- ETIM 5.0 Class-Description: Single-core cable
Conductor design
- Fine wire according to VDE 0295 class 5 / IEC 60228 class 5
Minimum bending radius
- According to EN 50565-1
- 4 x outer diameter (OD) for normal use; 2 x OD for careful bending
Nominal voltage
- U0/U: 300/500 V
Test voltage
- 2000 V
Current load capacity
- VDE 0298 part 4
- EN 50565-1/ VDE 0298-565-1
Temperature range
- Fixed installation: -40°C to +80°C
- Flexing: +5°C to +70°C
| Article number | Conductor cross-section (mm²) |
Outer diameter [mm] | Core colour | m/ring | Copper index (kg/km) | Weight (kg/km) |
| 8110033 | 1 | 2.8 | brown | 100 | 9.6 | 15 |
| 8110013 | 1 | 2.8 | black | 100 | 9.6 | 15 |
| 8110063 | 1 | 2.8 | grey | 100 | 9.6 | 15 |
| 8110023 | 1 | 2.8 | blue | 100 | 9.6 | 15 |
| 8110003 | 1 | 2.8 | green/yellow | 100 | 9.6 | 15 |
