Power and control cables
Various applications
PVC sheath, approved
LAPP KABEL ÖLFLEX® SF
Super-flexible H05VV-F power cable
ÖLFLEX® SF – H05VV-F harmonised PVC power cable. Super-flexible and colour-coded for various applications, especially for hand-held equipment
- Super-flexible cable for hand-held equipment
- Ozone-resistant according to EN 50396
- Ozone-resistant according to EN 50396
Benefits
- High acceptance in Europe due to harmonisation
Application range
- Very suitable for domestic appliances, electrical power tools, and handyman tools
- H05VV-F cable types must not be used in commercial premises, with the exception of offices.
- Not for permanent outdoor use.
Product features
- Flame-retardant according to IEC 60332-1-2
- Highly flexible / flexible at cold temperatures
- Design and geometry in compliance with harmonisation document
- Ozone-resistant according to EN 50396
Norm references / approvals
- H05VV-F according to EN 50525-2-11, from 6 cores based on EN 50525-2-11
Design
- Super-fine strands of bare copper wire with an individual wire diameter of 0.07 mm
- PVC core insulation, flexible at cold temperatures
- PVC sheath, flexible at low temperatures
orange (RAL 2003)
■ Technical data
Classification
- ETIM 5.0 Class-ID: EC001578
- ETIM 5.0 Class-Description: Flexible cable
Core identification code
- Coloured according to VDE 0293-308, see appendix T9
- From 6 cores: black with white numbers
Conductor design
- super-fine wire
(diameter of each wire is 0.07 mm)
Minimum bending radius
- Occasional flexing: 10 x outer diameter
- Fixed installation: 4 x outer diameter
Nominal voltage
- U0/U: 300/500 V
Test voltage
- 3000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- Flexing: -15°C to +60°C
| Article number | Number of cores and mm² per conductor | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| ÖLFLEX® SF | ||||
| 0027590 | 2 X 0.75 | 6.4 | 14.9 | 50 |
| 0027591 | 3 G 0.75 | 7.0 | 22.3 | 60 |
| 00275923 | 4 G 0.75 | 7.7 | 29.7 | 73 |
| 00275933 | 5 G 0.75 | 8.7 | 37.1 | 88 |
| 0027594 | 7 G 0.75 | 10.4 | 51.5 | 109 |
| 0027600 | 2 X 1.0 | 6.8 | 20.1 | 74 |
| 0027601 | 3 G 1.0 | 7.4 | 30.2 | 87 |
| 00276033 | 5 G 1.0 | 9.2 | 50.8 | 130 |
| 0027701 | 3 G 1.5 | 8.7 | 44.8 | 116 |
| 00277023 | 4 G 1.5 | 9.9 | 61.0 | 166 |
| 00277033 | 5 G 1.5 | 11.1 | 72.0 | 184 |
