UNITRONIC® LiYCY-CY
Shielded data cable with individually shielded cores
UNITRONIC® LiYCY-CY – shielded PVC data cable with additionally shielded cores, for use in strong electromagnetic interference fields
Benefits
- Overall shield minimises electrical
interference - Individually shielded cores minimise crosstalk between cables routed in parallel
Application range
- When a interference-free transmission of data has to be guaranteed in fields with strong interference, cables with individually-shielded cores and additional overall shielding are used
- Dry or damp rooms
Product features
- Wire shield can be used as outer conductor
- The cable remains flexible despite multiple screening
- Flame-retardant according to IEC 60332-1-2
Norm references / approvals
- Based on VDE 0812
Design
- Finely stranded bare copper wires
- Core insulation made of PVC
- Tin-plated copper braiding over each core
- Inner sheath made of PVC over each shielded core
- Tin-plated copper braiding
- Outer sheath made of PVC
Outer sheath colour: pebble grey (RAL 7032)
Classification
- ETIM 5.0 Class-ID: EC000104
- ETIM 5.0 Class-Description: Control cable
Core identification code
- DIN 47100, refer to appendix T9
Operating capacitance
- approx. 230 nF/km
Peak operating voltage
- (not for power applications)
250 V
Inductance
- approx. 0.2 mH/km
Conductor design
- Strand, fine-wire
Minimum bending radius
- Occasional flexing: 15 x outer diameter
- Fixed installation: 7.5 x outer diameter
Test voltage
- 1200 V
Temperature range
- Occasional flexing: -5°C to +70°C
- Fixed installation: -40°C to +80°C
| Article number | Number of cores and mm² per conductor |
Outer diameter [mm] | Copper index (kg/km) | Weight (kg/km) |
| UNITRONIC® LiYCY-CY | ||||
| 0032302 | 2 x 0.25 | 6.9 | 41.5 | 69 |
| 0032303 | 3 x 0.25 | 7.2 | 53 | 106 |
| 0032304 | 4 x 0.25 | 7.8 | 65 | 130 |
| 0032305 | 5 x 0.25 | 8.5 | 78 | 161 |
| 0032307 | 7 x 0.25 | 9.2 | 94 | 196 |
