UNITRONIC® LiFYCY (TP)
Shielded miniature data cable with twisted pairs
UNITRONIC® LiFYCY (TP) – shielded miniature PVC data cable with twisted pairs for use in areas where the smallest cross-sections are required
For microelectronic requirements
Benefits
- Space-saving due to small cable diameters
- Decoupling of circuits by means of
twisted-pair (TP) design (crosstalk effects) - Overall shield minimises electrical
interference
Application range
- For protection against high-frequency interference, shielded, fine-wire cables are used in many devices.
- When shielded cables with smallest dimensions are required
- Examples: Microelectronics, hearing aids etc.
Product features
- Very small dimensions
- Flame-retardant according to IEC 60332-1-2
Design
- Extra-fine wire strand made of bare copper wires
- Core insulation made of PVC
- Twisted pair (TP) structure
- Tin-plated copper braiding
- Outer sheath made of PVC
Outer sheath colour: pebble grey (RAL 7032)
Classification
- ETIM 5.0 Class-ID: EC000104
- ETIM 5.0 Class-Description: Control cable
Core identification code
- DIN 47100, refer to appendix T9
Operating capacitance
- C/C approx. 80 nF/km
- C/S approx. 120 nF/km
Peak operating voltage
- (not for power applications)
150 V
Coupling
- At 1 kHz: approx. 300 pF/100 m
Inductance
- approx. 0.65 mH/km
Conductor design
- Strand, extra-fine wire,
cross-section 0.08 mm²
Minimum bending radius
- Occasional flexing: 7.5 x outer diameter
- Fixed installation: 4 x outer diameter
Test voltage
- 800 V
Temperature range
- Occasional flexing: -5°C to +70°C
- Fixed installation: -40°C to +80°C
| Article number | Number of cores and mm² per conductor |
Outer diameter [mm] | Copper index (kg/km) | Weight (kg/km) |
| UNITRONIC® LiFYCY (TP) | ||||
| 0034231 | 4 x 2 x 0.08 | 5.1 | 19.4 | 37 |
| 0034233 | 8 x 2 x 0.08 | 6.7 | 23.7 | 76 |
■ Accessories
▯ SKINTOP® MS-SC-M
▯ EASY STRIP stripping and cutting tool
▯ Multipurpose shears A and B
▯ DATA STRIP stripping tool
