UNITRONIC® ST

Static shielded data cable based on UL AWM 2092

UNITRONIC® ST – PVC data cable with PE-insulated cores and static shielding, based on AWM 2092 for measurement, control and regulation technology

Interference signals

Benefits

  • Static shield made of aluminium-laminated plastic film with drain wire minimises the interference of high frequency, electromagnetic fields

Application range

  • Perfect for transmitting the smallest measurement and control signals in the case of minimal space requirements
  • Internal wiring of electronic equipment
  • For fixed and limited flexible installation
  • For use in dry, damp and wet rooms

Product features

  • Protection against interferences at medium and high frequencies thanks to aluminium-laminated plastic foil, combination of flexibility and good screening (normal requirements)
  • Flame-retardant according to IEC 60332-1-2

Norm references / approvals

  • Based on UL AWM Style 2092 / 2093

Design

  • 7-wire stranded wire made of tin-plated copper wires
  • Core insulation made of polyethylene (PE)
  • Plastic-laminated aluminium foil with tin-plated copper drain wire
  • Outer sheath made of PVC, outer sheath colour: similar to silver-grey/RAL 7001

Classification

  • ETIM 5.0 Class-ID: EC000104
  • ETIM 5.0 Class-Description: Control cable

Core identification code

  • 2 cores: black, transparent
    3 cores: black, red, transparent

Operating capacitance

  • C/C approx. 90 nF/km
  • C/S approx. 160 nF/km

Peak operating voltage

  • (not for power applications)
    500 V

Inductance

  • approx. 0.65 mH/km

Minimum bending radius

  • Occasional flexing: 10 x outer diameter
  • Fixed installation: 6 x outer diameter

Test voltage

  • 1500 V

Characteristic impedance

  • approx. 95 ohm

Temperature range

  • Occasional flexing: -5°C to +70°C
  • Fixed installation: -40°C to +80°C
Article number Number of conductors and AWG size Conductor
cross-section
(mm²)		 Core insulation
material		 Outer sheath
material		 Outer diameter
(mm)		 Copper index
(kg/km)		 Type no.
UNITRONIC® ST
0033000 2 x AWG 20/7 0.52 PE PVC 5.2 17.2 Belden 8762
0033001 3 x AWG 20/7 0.52 PE PVC 5.3 23 Belden 8772

■ Accessories
▯ UNIVERSAL STRIP stripping and cutting tool
▯ DATA STRIP stripping tool
