UNITRONIC® LiYD11Y
Data cable with copper wrapping and PUR outer sheath
UNITRONIC® LiYD11Y – UV-resistant data cable with copper wrapping, particularly suitable for use in harsh conditions thanks to the PUR outer sheath
Benefits
- Durable under harsh conditions thanks to robust PUR sheath material
- Resistant to contact with many mineral oil-based lubricants, diluted acids, aqueous alkaline solutions and other chemical media
Application range
- Intended for use in industrial environments, where cables require excellent mechanical and chemical resistance
- Shielded cables with small dimensions are suitable for use in computer systems, measurement, control and regulation technology, office equipment, scales.
- Can be used in dry or damp rooms
- Outdoor use is possible within the indicated temperature range
Product features
- PUR outer sheath, tear- and notch-resistant, resistant to mineral oils and abrasion
- Low-adhesive surface
- Good UV resistance
- Flame-retardant according to IEC 60332-2-2
- Spiral versions with similar properties are also available: “UNITRONIC® SPIRAL”
Norm references / approvals
- Based on VDE 0812
Design
- Extra-fine wire strand made of bare copper wires
- Core insulation made of PVC
- Wrapping made of bare copper wires
- Outer sheath made of PUR
Outer sheath colour: black (RAL 9005)
Classification
- ETIM 5.0 Class-ID: EC000104
- ETIM 5.0 Class-Description: Control cable
Core identification code
- DIN 47100 without colour repetition, refer to table T9
Operating capacitance
- C/C approx. 140 nF/km
- C/S approx. 150 nF/km
Peak operating voltage
- (not for power applications)
250 V
Inductance
- approx. 0.65 mH/km
Conductor design
- Strand, extra-fine wire
Minimum bending radius
- Occasional flexing: 10 x outer diameter
- Fixed installation: 6 x outer diameter
Test voltage
- 1200 V
Temperature range
- Occasional flexing: -5°C to +70°C
- Fixed installation: -40°C to +80°C
| Article number | Number of cores and mm² per conductor | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| UNITRONIC® LiYD11Y | ||||
| 0033202 | 2 x 0.14 | 4.1 | 9.6 | 20 |
| 0033203 | 3 x 0.14 | 4.3 | 11 | 25 |
| 0033204 | 4 x 0.14 | 4.5 | 12 | 27 |
| 0033205 | 5 x 0.14 | 4.8 | 14.4 | 33 |
| 0033206 | 6 x 0.14 | 5.5 | 17.6 | 38 |
| 0033207 | 7 x 0.14 | 5.9 | 21.5 | 41 |
| 0033212 | 12 x 0.14 | 7.2 | 33.2 | 62 |
| 0033218 | 18 x 0.14 | 8 | 44.2 | 83 |
| 0033302 | 2 x 0.25 | 4.7 | 11.8 | 25 |
| 0033303 | 3 x 0.25 | 5.3 | 15.6 | 31 |
| 0033304 | 4 x 0.25 | 5.6 | 18.2 | 36 |
| 0033305 | 5 x 0.25 | 6 | 21.4 | 42 |
| 0033306 | 6 x 0.25 | 6.8 | 26.1 | 49 |
| 0033312 | 12 x 0.25 | 8.4 | 48.1 | 81 |
| 0033318 | 18 x 0.25 | 9.7 | 69 | 117 |
