UNITRONIC® ROBUST
Halogen-free data cable with colour code according to DIN 47100 – resistant to a wide range of chemical media
UNITRONIC® ROBUST – data cable, weather-resistant, bio-oil-resistant, detergent-resistant and hot-water-resistant for use in the food industry and in composting plants.
- Excellent weather-resistance
- Good chemical resistance
Benefits
- Outstanding weather, ozone and UV resistance together with the wide temperature range enable versatile use for indoor and outdoor applications
- Resistant to contact with bio-oils, fats, waxes and their emulsions with a plant, animal or synthetic basis
- Good resistance to ammonia compounds and biogases
- Good resistance to cold and hot water as well as water-soluble cleaning and cooling agents
- Suitable for frequent steam cleaning
Application range
- Machine tool building, medical technology, laundries, car washing equipment, chemical industry, composting plants, sewage works
- Food and beverage industry, especially for production and processing of milk and meat products
- For data processing, measurement and control engineering, safety-related systems and as an electronics cable
- For indoor and outdoor use
Product features
- Good chemical resistance to ester-based hydraulic fluids
- Ozone-, UV- and weather-resistant according to EN 50396 and HD 605 S2
- Halogen-free as per IEC 60754-1, Low corrosivity/ acidity of combustion gases per IEC 60754-2, Low toxicity of comb. gases per EN 50305
- Low smoke density according to IEC 61034-2
Norm references / approvals
- Based on VDE 0812
- Certified resistance to disinfectant and cleaning solutions used in food and beverage industry
Design
- Fine-wire/multi-wire (0.34 mm²) strand made of bare copper wires
- Core insulation made of special halogen-free compound
- Outer sheath made of special TPE
- Sheath colour: Black
Classification
- ETIM 5.0 Class-ID: EC000830
- ETIM 5.0 Class-Description: Data cable
Core identification code
- DIN 47100 without colour repetition, refer to table T9
Operating capacitance
- C/C approx. 60 nF/km
Peak operating voltage
- (not for power applications)
at 0.14 mm²: 350 V
at ≥ 0.25 mm²: 500 V
Insulation-specific contact resistance
- > 20 GOhm x cm
Inductance
- approx. 0.65 mH/km
Conductor design
- Strands, fine-wire
0.34 mm²: 7-wire
Minimum bending radius
- Occasional flexing: 10 x outer diameter
- Fixed installation: 4 x outer diameter
Test voltage
- At 0.14 mm²: 1200 V
Temperature range
- Occasional flexing: -40°C to +90°C
- Fixed installation: -50°C to +90°C
| Article number | Number of cores and mm² per conductor | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| UNITRONIC® ROBUST | ||||
| 1032000 | 2 x 0.14 | 3.2 | 2.8 | 15 |
| 1032001 | 3 x 0.14 | 3.4 | 4.2 | 17 |
| 1032002 | 4 x 0.14 | 3.6 | 5.6 | 21 |
| 1032003 | 5 x 0.14 | 3.9 | 7 | 25 |
| 1032004 | 7 x 0.14 | 4.2 | 9.8 | 30 |
| 1032005 | 8 x 0.14 | 4.9 | 11.2 | 40 |
| 1032006 | 10 x 0.14 | 5.2 | 14 | 41 |
| 1032007 | 12 x 0.14 | 5.6 | 16.8 | 50 |
| 1032009 | 16 x 0.14 | 6.1 | 22.4 | 63 |
| 1032011 | 25 x 0.14 | 7.7 | 35 | 95 |
| 1032012 | 2 x 0.25 | 3.8 | 4.8 | 21 |
| 1032013 | 3 x 0.25 | 4 | 7.2 | 25 |
| 1032014 | 4 x 0.25 | 4.3 | 9.6 | 31 |
| 1032015 | 5 x 0.25 | 4.7 | 12 | 38 |
| 1032016 | 7 x 0.25 | 5.1 | 16.8 | 47 |
| 1032017 | 8 x 0.25 | 6.2 | 19.2 | 66 |
| 1032018 | 10 x 0.25 | 6.8 | 24 | 71 |
| 1032019 | 12 x 0.25 | 7 | 28.8 | 81 |
| 1032021 | 16 x 0.25 | 7.7 | 38.4 | 104 |
| 1032024 | 25 x 0.25 | 9.5 | 60 | 151 |
| 1032025 | 2 x 0.34 | 4.2 | 6.5 | 29 |
| 1032026 | 3 x 0.34 | 4.4 | 9.8 | 32 |
| 1032027 | 4 x 0.34 | 4.8 | 13.1 | 41 |
| 1032028 | 5 x 0.34 | 5.5 | 16.3 | 52 |
| 1032030 | 7 x 0.34 | 5.9 | 22.9 | 65 |
| 1032031 | 8 x 0.34 | 7.1 | 26.1 | 90 |
| 1032032 | 10 x 0.34 | 7.6 | 32.6 | 93 |
| 1032033 | 12 x 0.34 | 7.8 | 39.2 | 107 |
| 1032035 | 16 x 0.34 | 8.7 | 52.2 | 138 |
| 1032038 | 25 x 0.34 | 11.2 | 81.6 | 213 |
