UNITRONIC® ROBUST C (TP)
Halogen-free data cable with colour code according to DIN 47100 – resistant to a wide range of chemical media
UNITRONIC® ROBUST – data cable, weather-resistant, bio-oil-resistant, detergent-resistant and hot-water-resistant for use in the food industry and in composting plants.
- Excellent weather-resistance
- Good chemical resistance
Benefits
- Outstanding weather, ozone and UV resistance together with the wide temperature range enable versatile use for indoor and outdoor applications
- Resistant to contact with bio-oils, fats, waxes and their emulsions with a plant, animal or synthetic basis
- Good resistance to ammonia compounds and biogases
- Good resistance to cold and hot water as well as water-soluble cleaning and cooling agents
- Suitable for frequent steam cleaning
Application range
- Machine tool building, medical technology, laundries, car washing equipment, chemical industry, composting plants, sewage works
- Food and beverage industry, especially for production and processing of milk and meat products
- For data processing, measurement and control engineering, safety-related systems and as an electronics cable
- For indoor and outdoor use
Product features
- Good chemical resistance to ester-based hydraulic fluids
- Ozone-, UV- and weather-resistant according to EN 50396 and HD 605 S2
- Halogen-free as per IEC 60754-1, Low corrosivity/ acidity of combustion gases per IEC 60754-2, Low toxicity of comb. gases per EN 50305
- Low smoke density according to IEC 61034-2
Norm references / approvals
- Based on VDE 0812
- Certified resistance to disinfectant and cleaning solutions used in food and beverage industry
Design
- Fine-wire/multi-wire (0.34 mm²) strand made of bare copper wires
- Core insulation made of special halogen-free compound
- Twisted pair (TP) structure
- Tin-plated copper braiding
- Outer sheath made of special TPE
Outer sheath colour: black (RAL 9005)
Classification
- ETIM 5.0 Class-ID: EC000830
- ETIM 5.0 Class-Description: Data cable
Core identification code
- DIN 47100 without colour repetition, refer to table T9
Operating capacitance
- C/C approx. 60 nF/km
- C/S approx. 100 nF/km
Peak operating voltage
- (not for power applications)
at 0.14 mm²: 350 V
at ≥ 0.25 mm²: 500 V
Insulation-specific contact resistance
- > 20 GOhm x cm
Inductance
- approx. 0.65 mH/km
Conductor design
- Strands, fine-wire
0.34 mm²: 7-wire
Minimum bending radius
- Occasional flexing: 10 x outer diameter
- Fixed installation: 4 x outer diameter
Test voltage
- At 0.14 mm²: 1200 V
Temperature range
- Occasional flexing: -40°C to +90°C
- Fixed installation: -50°C to +90°C
| Article number | Number of cores and mm² per conductor | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| UNITRONIC® ROBUST C (TP) | ||||
| 1032100 | 2 x 2 x 0.14 | 5.3 | 16.1 | 31 |
| 1032101 | 3 x 2 x 0.14 | 5.8 | 19 | 38 |
| 1032102 | 4 x 2 x 0.14 | 6.2 | 23.1 | 46 |
| 1032103 | 5 x 2 x 0.14 | 6.4 | 27.2 | 54 |
| 1032104 | 6 x 2 x 0.14 | 7.1 | 31.3 | 63 |
| 1032105 | 8 x 2 x 0.14 | 8.2 | 43.4 | 90 |
| 1032106 | 10 x 2 x 0.14 | 8.7 | 50.9 | 93 |
| 1032107 | 12 x 2 x 0.14 | 8.9 | 56.6 | 102 |
| 1032108 | 2 x 2 x 0.25 | 6.3 | 22.7 | 43 |
| 1032109 | 3 x 2 x 0.25 | 7.1 | 28.9 | 56 |
| 1032110 | 4 x 2 x 0.25 | 7.6 | 38.3 | 72 |
| 1032111 | 5 x 2 x 0.25 | 7.9 | 45.1 | 85 |
| 1032112 | 6 x 2 x 0.25 | 8.5 | 48.7 | 96 |
| 1032113 | 8 x 2 x 0.25 | 10.3 | 64.3 | 135 |
| 1032114 | 2 x 2 x 0.34 | 7.1 | 27.6 | 56 |
| 1032115 | 3 x 2 x 0.34 | 7.8 | 38.8 | 74 |
| 1032116 | 4 x 2 x 0.34 | 8.4 | 47.5 | 90 |
| 1032117 | 5 x 2 x 0.34 | 8.8 | 58.2 | 110 |
| 1032118 | 1 x 2 x 0.5 | 5.6 | 20.1 | 37 |
| 1032119 | 2 x 2 x 0.5 | 7.9 | 40.3 | 72 |
| 1032120 | 3 x 2 x 0.5 | 8.7 | 51.7 | 91 |
| 1032121 | 4 x 2 x 0.5 | 9.4 | 64.1 | 112 |
| 1032122 | 5 x 2 x 0.5 | 10.3 | 76.6 | 141 |
| 1032123 | 6 x 2 x 0.5 | 11.1 | 91.7 | 170 |
| 1032124 | 8 x 2 x 0.5 | 13.1 | 123.2 | 238 |
| 1032125 | 10 x 2 x 0.5 | 14.5 | 146.4 | 247 |
| 1032126 | 2 x 2 x 0.75 | 8.5 | 48.4 | 84 |
| 1032127 | 3 x 2 x 0.75 | 9.4 | 68.9 | 114 |
| 1032128 | 4 x 2 x 0.75 | 10.7 | 86.2 | 149 |
| 1032129 | 6 x 2 x 0.75 | 12.1 | 131.9 | 225 |
| 1032130 | 8 x 2 x 0.75 | 14.7 | 168.2 | 315 |
| 1032131 | 2 x 2 x 1 | 9 | 64.1 | 98 |
| 1032132 | 3 x 2 x 1 | 10.4 | 83.5 | 135 |
| 1032133 | 4 x 2 x 1 | 11.3 | 105.7 | 168 |
