UNITRONIC® BUS PB 105
Fixed installation
Bus cable for PROFIBUS-DP, -FMS and FIP. Increases temperature resistance without additional protection. Flame retardant and oil resistant. Temp. range from -30°C to +105°C
Benefits
- A standard PROFIBUS cable can only be used up to a max. temperature of 80°C
- This enables an extended area of application
Application range
- Cable has been designed for use in factory halls where temperatures may reach up to max. 105°C.
Product features
- Flame-retardant according to IEC 60332-1-2
- Oil-resistant
Design
- Braided conductor, 7-wire, bare
- Polypropylene core insulation
- Overall shielding with copper braiding and plastic-laminated aluminium foil
- Tin-plated copper wire braiding
- PVC outer sheath for use up to 105°C
Classification
- ETIM 5.0 Class-ID: EC000830
- ETIM 5.0 Class-Description: Data cable
Operating capacitance
- approx. 28.5 nF/km
Peak operating voltage
- max. 100 V (not for power applications)
Minimum bending radius
- Fixed installation: 45 mm once
- Flexing: 65 mm
Test voltage
- Core/Core: 1500 V eff.
- Core/Shield: 1500 V
Characteristic impedance
- (3 – 20 MHz): 150 ±15 ohm
Temperature range
- -30°C to +105°C
| Article number | Article designation | Number of pairs and conductor diameter (mm) |
Outer diameter [mm] | Copper index (kg/km) | Weight (kg/km) |
| 2170630 | UNITRONIC®BUS PB 105 | 1x2x0,64 | 8 | 26 | 55 |
