UNITRONIC® BUS PB 105 plus
Bus cable for PROFIBUS-DP, -FMS and FIP. Increases temperature resistance without additional protection. Temperature range of -40°C to +105 °C (short-term: up to +120°C)
- Bus system PROFIBUS-DP/FMS/FIP
- Lapp Kabel is a member of the PROFIBUS user organisation (PNO)
Benefits
- No need for additional cable protection against high temperatures
- High temperature resistance
Application range
- for installation in hollow shaft between gear unit and pitch system
- suitable for fixed installation and occasionally flexible use in high temperature areas
Product features
- Permanent load up to +105°C, temporary load +120°C
Norm references / approvals
- In accordance with DIN 19245 and EN 50170, e.g. for SIEMENS SIMATIC NET, also suitable for FIP (Factory Instrumentation Protocol)
Design
- Braided conductor, 7-wire, bare
- Core insulation: Polypropylene (PP)
- Overall shielding with copper braiding and plastic-laminated aluminium foil
- Outer sheath based on TPE
Classification
- ETIM 5.0 Class-ID: EC000830
- ETIM 5.0 Class-Description: Data cable
Operating capacitance
- (800 Hz): max. 30 nF/km
Peak operating voltage
- (not for power applications)
250 V
Minimum bending radius
- Fixed installation: 45 mm once
- Flexing: 65 mm
Test voltage
- Core/Core: 1500 V eff.
- Core/Shield: 1500 V eff.
Characteristic impedance
- (3 – 20 MHz): 150 ±15 ohm
Temperature range
- Fixed installation: -40°C to +105°C
- short-term: up to +120°C
| Article number | Article designation | Number of pairs and conductor diameter (mm) |
Outer diameter [mm] | Copper index (kg/km) |
| 2170635 | UNITRONIC® BUS PB 105 plus | 1x2x0,64 | 8 | 30.1 |
