UNITRONIC® BUS PB FRNC FC
Fixed installation
Bus cable for PROFIBUS-DP, -FMS and FIP. Cable is UL/CSA-certified, halogen-free, has enhanced flame retardance, oil resistance. Temperature range from -30°C to +80°C
FRNC = Flame Retardant Non Corrosive
– Reduction of flame propagation and
density and toxicity of smoke gases
in the event of fire
– Minimisation of fire damage to buildings
and production facilities
– Safety for maintenance personnel and
in areas with a high density of people
Benefits
- Halogen-free and highly flame-retardant
- Cables can be used for PROFIBUS-DP as well as PROFIBUS-FMS and FIP
- For use wherever the combination of a halogen-free outer sheath with properties similar to polyurethane and enhanced flame-retardance is required
- Fast Connect (FC) cable design
Application range
- This cable provides special advantages in sensitive areas where fire propagation must be avoided and the presence of toxic fumes in the event of a fire would cause personal injury and damage to equipment.
Product features
- The cable is UL/CSA-certified (CMG)
- Halogen-free
- Highly flame-retardant in accordance with IEC 60332-3 and FT4
- Oil-resistant
- Based on the bit rates listed, in accordance with PNO specifications the following maximum cable lengths for a bus segment apply
(cable type A, PROFIBUS-DP):
93.75 kbit/s = 1200 m
187.5 kbit/s = 1000 m
500 kbit/s = 400 m
1.5 Mbit/s = 200 m
12.0 Mbit/s = 100 m
Design
- Solid, bare, single-wire copper conductor
- PE core insulation
- Inner sheath, screening foil and braiding
- Thermoplastic outer sheath
- Colour: violet (RAL 4001)
Classification
- ETIM 5.0 Class-ID: EC000830
- ETIM 5.0 Class-Description: Data cable
Certifications
- UL/CSA (CMG)
Operating capacitance
- approx. 28.5 nF/km
Peak operating voltage
- (not for power applications)
250 V
Minimum bending radius
- 80 mm
Test voltage
- Core/Core: 1500 V eff.
- Core/Shield: 1500 V
Characteristic impedance
- (3 – 20 MHz): 150 ±15 ohm
Temperature range
- -30°C to +80°C
| Article number | Article designation | Number of pairs and conductor diameter (mm) |
Outer diameter [mm] | Copper index (kg/km) | Weight (kg/km) |
| 2170853 | UNITRONIC® BUS PB FRNC FC | 1x2x0,64 | 8 | 30.1 | 75 |
■ Accessories
▯ EPIC® Data Connectors
▯ FC STRIP stripping tool
