UNITRONIC® BUS PB BURIAL FC
Suitable for outdoor use and direct burial, UV-resistant
Bus cables can be used for PROFIBUS-DP, PROFIBUS-FMS as well as FIP. Robust, UV-resistant and weatherproof. Temperature range from -40°C to +60°C
Benefits
- Fast Connect (FC) cable design
- Rugged, UV-resistant and weatherproof
- Cables can be used for PROFIBUS-DP as well as PROFIBUS-FMS and FIP
Application range
- PROFIBUS DP (in accordance with DIN 19245 and EN 50170, e.g. for SIEMENS SIMATIC® NET, also for FIP – Factory Instrumentation Protocol).
Product features
- Second PE outer sheath
Design
- Solid and bare copper conductor
- Foam Skin – core insulation (O2YS)
- Overall shielding with copper braiding and plastic-laminated aluminium foil
- Tin-plated copper wire braiding
- PVC sheath, violet, OD 8 mm
PE sheath, black, OD 10.8 mm
Classification
- ETIM 5.0 Class-ID: EC000830
- ETIM 5.0 Class-Description: Data cable
Operating capacitance
- (800 Hz): max. 30 nF/km
Peak operating voltage
- (not for power applications)
100 V
Minimum bending radius
- Fixed installation: 3.5 x cable diameter once
- Fixed installation: 7.5 x outer diameter
Test voltage
- 3600 V DC (3 sec.)
Characteristic impedance
- 150 ±15 ohm
Temperature range
- -40°C to +60°C
| Article number | Article designation | Number of pairs and conductor diameter (mm) |
Outer diameter [mm] | Copper index (kg/km) | Weight (kg/km) |
| Suitable for outdoor use and direct burial | |||||
| 2170323 | UNITRONIC®BUS PB BURIAL FC | 1x2x0,64 | 10.8 | 26 | 115 |
