UNITRONIC® BUS PB Y 7-W FC BK
Suitable for outdoor installation, UV-resistant
Bus cable for PROFIBUS-DP, -FMS and FIP. Fast Connect (FC) cable design, UV-resistant and weather-resistant. Temperature range from -40°C to +80°C
Benefits
- UV- and weather-resistant in black
- 7-W: 7-wire, e.g. for applications
where vibrations occur - Fast Connect (FC) cable design
- Cables can be used for PROFIBUS-DP as well as PROFIBUS-FMS and FIP
Application range
- PROFIBUS DP (in accordance with DIN 19245 and EN 50170, e.g. for SIEMENS SIMATIC® NET, also for FIP – Factory Instrumentation Protocol).
Product features
- PVC compound TM2 according to EN 50363-4-1
- Highly resistant to a multitude of oils, acids and other chemical media at room temperature
Design
- Braided conductor, 7-wire, bare
- Foam Skin – core insulation (O2YS)
- Overall shielding with copper braiding and plastic-laminated aluminium foil
- Tin-plated copper wire braiding
- PVC outer sheath, black
Classification
- ETIM 5.0 Class-ID: EC000830
- ETIM 5.0 Class-Description: Data cable
Operating capacitance
- (800 Hz): max. 30 nF/km
Peak operating voltage
- (not for power applications)
250 V
Minimum bending radius
- Fixed installation: 8 x outer diameter
- Flexing: 15 x outer diameter
Test voltage
- Core/Core: 1500 V eff.
- Core/Shield: 1500 V
Characteristic impedance
- 150 ±15 ohm
Temperature range
- Flexing: -10°C to +70°C
- Fixed installation: -40°C to +80°C
| Article number | Article designation | Number of pairs and conductor diameter (mm) |
Outer diameter [mm] | Copper index (kg/km) | Weight (kg/km) |
| 2170310 | UNITRONIC®BUS PB Y 7-W FC BK | 1x2x0.64 | 7.8 | 30.1 | 80 |
