UNITRONIC® BUS PB HEAT 180
Bus cable for PROFIBUS-DP, -FMS and FIP. Increases temperature resistance without additional protection. Increases oil-resistance. Temperature range from -50 to +180°C
Benefits
- No need for additional cable protection against high temperatures
- High temperature resistance
Application range
- Fixed installation
- For use in high temperature areas with up to 180°C
Product features
- High oil resistance
Design
- Solid and bare copper conductor
- Core insulation fluoroethylene
- Overall shielding with copper braiding and plastic-laminated aluminium foil
- Screening braid made of tin-plated copper wires
- Outer sheath made of fluorinated ethylene propylene, FEP, violet
Classification
- ETIM 5.0 Class-ID: EC000830
- ETIM 5.0 Class-Description: Data cable
Operating capacitance
- approx. 28 nF / km
Peak operating voltage
- (not for power applications)
250 V
Minimum bending radius
- Repeated: 7 x outer diameter
Once: 5 x outer diameter
Test voltage
- 3600 V DC (3 sec.)
Characteristic impedance
- (3 – 20 MHz): 150 ±15 ohm
Temperature range
- -50 to +180°C
| Article number | Article designation | Number of pairs and conductor diameter (mm) |
Copper index (kg/km) | Weight (kg/km) |
| 3031981 | UNITRONIC®BUS PB HEAT 180 | 1x2x0.64 | 21.7 | 0.064 |
