Benefits

• Fast Connect (FC) system
• For use wherever the combination of a halogen-free outer sheath with properties similar to polyurethane and enhanced flame-retardance is required
• For highly flexible applications (drag chains, frequently moving machine components)
• Cables can be used for PROFIBUS-DP as well as PROFIBUS-FMS and FIP

Application range

• For highly flexible use in power chains, permanently moving machines and linear robots
• This cable provides special advantages in sensitive areas where fire propagation must be avoided and the presence of toxic fumes in the event of a fire would cause personal injury and damage to equipment.

Product features

• The cable is UL/CSA-certified (CMG)
• Halogen-free
• Highly flame-retardant in accordance with IEC 60332-3 and FT4
• Oil-resistant
• Based on the bit rates listed, in accordance with PNO specifications the following maximum cable lengths for a bus segment apply
  (cable type A, PROFIBUS-DP):
  93.75 kbit/s = 1200 m
  187.5 kbit/s = 1000 m
  500 kbit/s = 400 m
  1.5 Mbit/s = 200 m
  12.0 Mbit/s = 100 m

Design

• Stranded bare copper wire
• Foam Skin – core insulation (O2YS)
• Overall shielding with copper braiding and plastic-laminated aluminium foil
• Screening braid made of tin-plated copper wires
• Outer sheath: Polyurethane (PUR) compound
