UNITRONIC® BUS IS
Data transmission to agricultural vehicles. Resistant against oil, benzine, diesel and UV. According to ISO 11783-2:2012. Temperature range from -40°C to +85°C
- ISOBUS is a bus system for agricultural vehicles, which is standardised in the international standard ISO 11783-2
- Lapp cable is member of the AEF – Agricultural Industry Electronics Foundation
Benefits
- Cable according to ISOBUS standard (ISO 11783-2) for use in agricultural vehicles
- HYBRID: Cable for data transmission and power supply
Application range
- For outdoor applications
- Connection cable between tractor and pulled machinery
Product features
- Flame-retardant according to IEC standard 60332-1
- Resistant to oil, petrol and diesel
- UV-resistant
- PUR (polyurethane) version with increased robustness, UV resistance and halogen-free
Norm references / approvals
- ISO 11783-2:2012
Design
- 4x 0.5 mm² (red, yellow, black, green)
2x 2.5 mm² (red, black)
2x 6 mm² (red, black) - Fine-wired copper conductor made of bare copper wires in line with braided conductor class 5 according to IEC 60228 / VDE 0295
- Sheath: Black PVC or PUR special compound
Classification
- ETIM 5.0 Class-ID: EC000830
- ETIM 5.0 Class-Description: Data cable
Peak operating voltage
- 60 V
Test voltage
- 0.5 mm – 2.5 mm² core / core = 1.5 kV;
6 – 10 mm² core / core = 2.5 kV
Characteristic impedance
- Characteristic impedance 75 ohm
Temperature range
- PUR: -40°C to +85°C
- PVC: -30°C to +85°C
| Article number | Article designation | Number of pairs and cable diameter | Copper index (kg/km) |
| 2170560 | UNITRONIC® BUS IS PVC | 2×6+2×2,5+1x4x0,5 | 182.4 |
| 2170561 | UNITRONIC® BUS IS PUR | 2×6+2×2,5+1x4x0,5 | 182.4 |
