UNITRONIC® BUS CC FD P FRNC
CC-Link provide efficient, integrated production and process automation. UV-resistant and flame-retardant. AWM style 300V. Temperature range from -40°C to +80°C
Lapp Kabel is a regular member of the user organisation CC-Link Partner Association (CLPA), Japan.
Benefits
- The CC-Link® system was developed by Mitsubishi Electric Automation, Japan.
Application range
- CC-Link® (Control & Communication Link) = fieldbus network, for both control as well as information data to ensure efficient, integrated manufacturing and process automation.
- For highly flexible applications (drag chains, frequently moving machine components)
Product features
- Transmission rate in relation to the distance
- 156 kbit/s 1.200 m
625 kbit/s 600 m
2,5 Mbit/s 200 m
5,0 Mbit/s 110-150 m
10 Mbit/s 50-100 m - Halogen-free and flame-retardant (IEC 60332-1-2)
Norm references / approvals
- AWM 20233 80°C 300V
Classification
- ETIM 5.0 Class-ID: EC000830
- ETIM 5.0 Class-Description: Data cable
Certifications
- UL AWM Style 20233
Peak operating voltage
- 300 V
Conductor resistance
- 11 ohm/1,000 ft. (305 m) at 20°C
Minimum bending radius
- Fixed installation: 4 x outer diameter
- Flexing: 8 x outer diameter
Test voltage
- 2000 V
Characteristic impedance
- 110 ohm at 1 MHz
Temperature range
- -40°C to +80°C
| Article number | Article designation | Number of cores and AWG size | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| UNITRONIC® BUS CC FD P FRNC | |||||
| 2170370 | UNITRONIC® BUS CC FD P FRNC | 3 x 1 x AWG20 | 8.5 | 39.9 | 84 |
