1U Cat 6 48-port Unshielded Dual IDC Patch Panel
Features
• Dual IDC allows both 110 and Krone tools to be used for termination
• Comes with front labels
• Comes with rear wire manager bar
• Support both T568A and T568B wiring
• Support Gigabit Ethernet application
Electrical Characteristics
| IDC | Insulation Resistance | Dielectric Withstand Voltage |
| 22-24 AWG Solid Wire | 500 mΩ @ 100 VDC |
1000 VAC @ RMS, 60 Hz 1 min |
Mechanical and Physical Characteristics
| IDC | Housing | RJ45 Jack | RJ45 Jack Insertion Cycle |
| Phosphor Bronze Alloy with 100u” Sn Alloy |
PC UL94V-0 |
8P8C Phosphor Bronze Alloy plated 50u” gold, plated over 70~100u” Nickel |
> 750 cycles (min) |
Standards
• ANSI/TIA-568-C.2
• ISO/IEC 11801
• CENELEC EN50173
• UL 1863
| Part No. | Description |
| 302-201601-48AB | 1U Cat 6 48-port Unshielded Dual IDC Patch Panel |
