Cat 6 Unshielded 180° Quick Crimp Keystone Jack
Description
Alantek Cat6 Slim Line 180° Quick Crimp Keystone Jack are designed to provide superior performance, reliabilityand fast termination. It advanced circuit design provide optimum signal quality, allowing it to exceed TIA/EIA and ISO Category 6 performance standards. The Slim design offers a smallerfootprint maximizing space in confined area.
Application
Suitable for used in 10Base-T to Gigabit Ethernet application. Support all type of Alantek faceplate and Modular Patch Panel.
Standard
• ANSI/TIA 568C.2 Category 6
• ISO 11801 Class D Standard
• TIA/EIA TSB-40
• CENELEC EN50173
• UL 1863
• UL94V-0
Features
• Slim, Modular and Low Profile design allow high density application
• IDC is configured at 180° to Jack to allow easy reartermination and allow quick termination by Quick Crimp tool.
• Support both T568A and T568B wiring
• Support 10Base-T to Gigabit Ethernet application
Characteristics
• Insulation Resistance: 500 m-Ω
• Dielectric Withstand Voltage: 1000 V AC
• RMS, 60 Hz 1 min
• Housing: PC UL94V-0 (High Impact, Fire retardant plastic)
• Contact: Phosphor Bronze Alloy plated with 50 microngold
• 750 Cycles (min) Insertion and Extraction life
• IDC: Phosphor Bronze Alloy with 100 micron Sn Alloy
• Accept 22-24 AWG Solid Wire
| Part No. | Description |
| 302-2QX618-WHAB | Cat 6 Unshielded Slim Line 180° Quick Crimp Keystone Jack |
