Hạt Mạng Alantek ( 302-203FA6-1550 ) Cat 6A Shielded RJ45 Plug 8P8C 1.5mm 50µm | Chính Hãng – Giá tốt Nhất
Cat 6A Shielded RJ45 Plug 8P8C 1.5mm 50µm
Electrical
• UL applications: 250 Volts AC max., at 2 Amps
• Dielectric withstanding voltage : 500 Volts AC
• Insulation resistance: 100 MΩ
• Termination: resistance 20mΩ max
Mechanical
• Cable-to-plug tensile strength : 20 pound min.
• Durability : 200 mating cycles.
Material & Finish
• Housing: Polycarbonate, ul94v-0
• Color : Transparent
• Contact blade: Copper alloy.
• Conductor : stranded & solid wire 22-24AWG (it can be used for the wire O.D. from ø1.05~ø1.15)
• Gold plating: 50u”
| Part No. | Description |
| 302-203FA6-1550 | Cat 6A Shielded RJ45 Plug 8P8C 1.5mm 50µm |
DATA SHEET
