Power and control cables
Harsh conditions
High mechanical and chemical resistance
LAPP KABEL ÖLFLEX® ROBUST 200
Tried-and-tested all-weather connection cable – resistant against a wide range of chemical media
ÖLFLEX® ROBUST 200 – connection cable, weather-resistant, bio-oil-resistant, detergent-resistant and hot-water-resistant for use in the food industry and in composting plants.
- Excellent weather-resistance
- Good chemical resistance
- Voltage class 450/750 V
Benefits
- Outstanding weather, ozone and UV resistance together with the wide temperature range enable versatile use for indoor and outdoor applications
- Resistant to contact with bio-oils, fats, waxes and their emulsions with a plant, animal or synthetic basis
- Good resistance to ammonia compounds and biogases
- Good resistance to cold and hot water as well as water-soluble cleaning agents
- Suitable for frequent steam cleaning
Application range
- Machine tool building, medical technology, laundries, car washing equipment, chemical industry, composting plants, sewage works
- Food and beverage industry, especially for production and processing of milk and meat products
- Agricultural equipment
- For indoor and outdoor use
Product features
- Good chemical resistance to ester-based hydraulic fluids
- Ozone-, UV- and weather-resistant according to EN 50396 and HD 605 S2
- Flexible at temperatures down to -40 °C
- Low-capacitance design
- Colour-coded up to 5 cores
Norm references / approvals
- Based on EN 50525-2-51
- Certified resistance to disinfectant and cleaning solutions used in food and beverage industry
Design
- Fine-wire, bare copper conductor
- Core insulation made of modified PP
- Cores twisted in layers
- Outer sheath made of special TPE
- Sheath colour: black
■ Technical data
Classification
- ETIM 5.0 Class-ID: EC001578
- ETIM 5.0 Class-Description: Flexible cable
Core identification code
- Up to 5 cores: according to VDE 0293-308 (appendix T9)
- From 6 cores: black with white numbers
Conductor design
- Fine wire according to VDE 0295,
class 5 / IEC 60228 class 5
Minimum bending radius
- Occasional flexing: 10 x outer diameter
- Fixed installation: 4 x outer diameter
Nominal voltage
- U0/U: 450/750 V
Test voltage
- 4000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- Occasional flexing: -40°C to +80°C
- Fixed installation: -50°C to +80°C
| Article number |
Number of cores and mm² per conductor |
Outer diameter (mm) |
Copper index (kg/km) |
Weight (kg/km) |
| ÖLFLEX® ROBUST 200 | ||||
| 0021800 | 2 X 1.0 | 8 | 19,2 | 65 |
| 0021801 | 3 G 1.0 | 8,4 | 29 | 79 |
| 0021802 | 4 G 1.0 | 9,2 | 38,4 | 96 |
| 0021803 | 5 G 1.0 | 10 | 48 | 113 |
| 0021805 | 2 X 1.5 | 8,6 | 29 | 78 |
| 0021806 | 3 G 1.5 | 9,1 | 43 | 97 |
| 0021807 | 4 G 1.5 | 9,9 | 58 | 122 |
| 0021808 | 5 G 1.5 | 10,8 | 72 | 146 |
| 0021809 | 7 G 1.5 | 13,5 | 101 | 208 |
| 0021810 | 2 X 2.5 | 9,8 | 48 | 114 |
| 0021811 | 3 G 2.5 | 10,4 | 72 | 144 |
| 0021812 | 4 G 2.5 | 11,5 | 96 | 181 |
| 0021813 | 5 G 2.5 | 13,1 | 120 | 222 |
| 0021814 | 7 G 2.5 | 15,9 | 168 | 312 |
| 0021816 | 3 G 4 | 12,4 | 115,2 | 215 |
| 0021817 | 4 G 4 | 14 | 154 | 273 |
| 0021818 | 5 G 4 | 15,8 | 192 | 333 |
| 0021822 | 4 G 6 | 15,7 | 230 | 378 |
| 0021823 | 5 G 6 | 17,2 | 288 | 463 |
| 0021825 | 4 G 10 | 19,4 | 384 | 570 |
| 0021826 | 5 G 10 | 21,4 | 480 | 770 |
| 0021828 | 4 G 16 | 22,4 | 614 | 885 |
| 0021829 | 5 G 16 | 24,6 | 768 | 1100 |
| 0021831 | 4 G 25 | 27 | 960 | 1365 |
| 0021833 | 4 G 35 | 29,7 | 1,344.0 | 1773 |
| 0021836 | 4 G 50 | 36,2 | 1,920.0 | 3454 |
