UNITRONIC® BUS ASI FD

Highly flexible application

Communication at sensor/actuator level. Halogen-free (PUR), UL-approval, oil-resistant (TPE). Temperature range from -40°C to +105°C (TPE)

  • “FD” = suitable for drag chains
  • “LD” = Long Distance

Temperature-resistant Power chain Halogen-free Industrial machinery and plant engineering Automation & fältinstallation

Benefits

  • The new BUS ASI LD 2 x 2.5 (long distance) now allows modules located even further away to be connected. Additional AS-I supplies can be reduced.
    BUS ASI LD is downwards-compatible with version 1.5.
  • For highly flexible applications (power chains, moving machine parts)
  • High oil resistance

Application range

  • Communication at sensor/actuator level
  • Sensor/actuator wiring

Product features

  • PUR versions are halogen-free according to IEC 60754-1
  • Flame-retardant according to IEC 60332-1-2, UL FT-2 flame test
  • Data and power are transmitted via an unshielded, geometrically coded two-wire flat cable (protection against polarity reversal).
  • The conductor is contacted by “piercing technology” within the ASI modules.
  • The sensors are connected to the ASI modules (coupling modules) using round cables (connection cables).

Norm references / Approvals

  • ASI is standardised Europe-wide in EN 50295 and internationally in IEC 62026-2
  • TPE version: UL AWM Style 2103
    CSA AWM II A/B
  • PUR versions: UL AWM Style 20549

Product Make-up

  • Extra-fine wire, tin-plated copper strands
  • Core insulation (blue and brown)
  • Profiled outer sheath made of thermoplastic elastomers (TPE) or polyurethane (PUR)
  • Colour: yellow (RAL 1023) or black (RAL 9005)

Classification

  • ETIM 5.0 Class-ID: EC000830
  • ETIM 5.0 Class-Description: Data cable

Peak operating voltage

  • 300 V (not for power applications)

Conductor resistance

  • 1.5 mm²: max. 13.7 ohm/km
  • 2.5 mm²: max. 8.21 ohm/km

Minimum bending radius

  • Fixed installation: 12 mm
  • Flexing – without fixed routing: 24 mm
    Flexing – without fixed routing: 60 mm (15xD)

Test voltage

  • Core/Core: 2000 V

Temperature range

  • Fixed installation:
    -40°C to +80°C (TPE +105°C)
  • Flexing – without fixed routing:
    -30°C to +70°C (TPE +105°C)
Article number Article designation Outer sheath
material		 Outer sheath colour Application Number of cores and mm² per conductor Copper index [kg/km] Weight [kg/km]
For highly flexible applications (power chains, moving machine parts)
2170357 UNITRONIC® BUS ASI FD P FRNC PUR UL/CSA (AWM) yellow Data and power transmission 2 x 1,5 29 64
2170358 UNITRONIC® BUS ASI FD P FRNC PUR UL/CSA (AWM) black Transmission of 30 V DC auxiliary power 2 x 1,5 29 64
2170317 UNITRONIC® BUS ASI LD FD P PUR UL/CSA (AWM) yellow Data and power transmission 2 x 2,5 48 74
2170318 UNITRONIC® BUS ASI LD FD P PUR UL/CSA (AWM) black Transmission of 30 V DC auxiliary power 2 x 2,5 48 74
2170830 UNITRONIC® BUS ASI FD (TPE) A TPE UL/CSA (AWM) yellow Data and power transmission 2 x 1,5 29 64
2170831 UNITRONIC® BUS ASI FD (TPE) A TPE UL/CSA (AWM) black Transmission of 30 V DC auxiliary power 2 x 1,5 29 64
