UNITRONIC® SENSOR

Flexible cable for sensor/actuator cabling

Cables supplied by the metre for sensor/actuator cabling for fixed installation and occasional flexible use. To connect to M8, M12 plug connectors.

  • Easy cable preperation
  • UL recognized (LifYY A)

UV-resistant Automation & fältinstallation

Benefits

  • Easy installation (through cable trays, tubes, cabinets)
  • Easy stripping and processing
  • Space-saving due to compact dimensions

Application range

  • Automation technology
  • Sensor/actuator cabling

Product features

  • Core colour code in accordance with DIN EN 50044
  • Black version: UV-resistant
  • For higher mechanical stress (LifY11Y/Desina®)

Norm references / Approvals

  • UL recognized (LifYY A)

Product Make-up

  • Extra-fine wire strand made of bare copper wires
  • Core insulation: PVC
  • Core colours:
    3-pin: bn, bu, bk
    4-pin: bn, wh, bu, bk
    5-pin: bn, wh, bu, bk, gy
  • DESINA® 4×0.34: bn, wh, bu, bk
  • Outer sheath: PVC or PUR
  • Sheath colour: black (RAL 9005)
  • DESINA® yellow (RAL 1021)

Classification

  • ETIM 5.0 Class-ID: EC001578
  • ETIM 5.0 Class-Description: Flexible cable

Peak operating voltage

  • 300 V (not for power applications)

Conductor stranding

  • Extra-fine wire according to VDE 0295, class 6 / IEC 60228 class 6

Minimum bending radius

  • Flexing: 15 x outer diameter
  • Fixed installation: 8 x outer diameter

Temperature range

  • PVC/PVC:
    Fixed installation: -40°C to +80°C
    Flexing: -5°C to +80°C
  • PVC/PUR:
    Fixed installation: -30°C to +80°C
    Flexing: -10°C to +80°C
Article number Article designation Dimensions (mm²) Outer diameter (mm) Core/outer sheath material Colour Copper index (kg/km)
7038860 LifYY 4 x 0.34 4,8 PVC/PVC black 13,1
UNITRONIC® SENSOR PVC
7038898 LifYY 3×0.25 3,8 PVC/PVC black 7,5
7038899 LifYY 4×0.25 4,2 PVC/PVC black 10,2
7038900 LifYY 3 x 0.34 4,1 PVC/PVC black 9,8
7038901 LifYY 4 x 0.34 4,4 PVC/PVC black 13
7038902 LifYY 5 x 0.34 4,8 PVC/PVC black 16
UNITRONIC® SENSOR PVC UL
7038903 LifYY A 3×0.25 4,3 PVC/PVC black yes
7038904 LifYY A 4×0.25 4,6 PVC/PVC black yes
7038905 LifYY A 3 x 0.34 4,4 PVC/PVC black yes
7038906 LifYY A 4 x 0.34 4,8 PVC/PVC black yes
7038907 LifYY A 5 x 0.34 5,2 PVC/PVC black yes
UNITRONIC® SENSOR PVC/PUR
7038861 LifY11Y 4 x 0.34 4,8 PVC/PUR black 13,1
7038862 LifY11Y 5 x 0.25 4,9 PVC/PUR black 12
0040434 DESINA 4 x 0.34 5,2 PVC/PUR yellow 13,5
