ÖLFLEX® POWER LV (N)2XYRY SC
Low voltage power cables

• Low voltage power cable 0.6/1 kV

• Single core, Armoured (AWA)
  XLPE/PVC/AWA/PVC
• product information (PDF)

■ Application range

• For main power distribution and lighting circuits in residential, industrial and commercial areas

• Power and control circuit

• Telecom power supply

• Suitable for direct burial installations as well as in air or ducts

■ Product features

• Cable construction in acc. to IEC 60502-1

• Flame-retardant acc. to IEC 60332-1-2

• UV-resistant outer sheath for outdoor application

■ Product Make-up

• Stranded plain annealed copper wires in circular shape conductor

• XLPE core insulation

• PVC inner sheath, black

• Aluminium wire armoured

• PVC outer sheath, black

• Also available in LSHF version

■ Technical data

Based on
IEC 60502-1
Specific insulation resistance
> 1000 GOhm x cm
Conductor stranding
acc. to IEC 60228 Cl.2
Minimum bending radius
10 x cable diameter
Nominal voltage
U0/U: 600/1000 V
Test voltage
3500 V
Temperature range
Fixed installation: -40°C to +90°C
