ÖLFLEX® POWER LV (N)YYRY
Low voltage power cables
- Low voltage power cable 0.6/1 kV
- Armoured, PVC/PVC/SWA/PVC
- product information (PDF)
■ Application range
- For main power distribution and lighting circuits in residential, industrial and commercial areas
- Power and control circuit
- Telecom power supply
- Suitable for direct burial installations as well as in air or ducts
■ Product features
- Cable construction in acc. to IEC 60502-1
- Flame-retardant acc. to IEC 60332-1-2
- UV-resistant outer sheath for outdoor application
■ Product Make-up
- Stranded plain annealed copper wires in circular shape conductor
- PVC core insulation
- PVC inner sheath, black
- Galvanized steel wire armoured
- PVC outer sheath, black
- Also available in LSHF version
■ Technical data
Core identification code
acc. to BS 7671:2004
Based on
IEC 60502-1
Specific insulation resistance
> 10 GOhm x cm
Conductor stranding
acc. to IEC 60228 Cl.2
Minimum bending radius
10 x cable diameter
Nominal voltage
U0/U: 600/1000 V
Test voltage
3500 V
Temperature range
Fixed installation: -20°C to +70°C
| Article number | Number of cores and mm² per conductor | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| 3803077 | 2 x 1.5 | 13,8 | 28,5 | 335 |
| 3800199 | 3 x 1.5 | 14,3 | 42,8 | 375 |
| 3800200 | 4 x 1.5 | 15,1 | 57 | 425 |
| 3800201 | 5 x 1.5 | 16 | 70 | 480 |
| 3800202 | 7 x 1.5 | 17,7 | 98 | 644 |
| 3800203 | 10 x 1.5 | 21 | 140 | 835 |
| 3800204 | 12 x 1.5 | 21,5 | 168 | 899 |
| 3803078 | 14 x 1.5 | 23 | 196 | 1113 |
| 3803079 | 16 x 1.5 | 24 | 224 | 1188 |
| 3800205 | 19 x 1.5 | 24,8 | 266 | 1305 |
| 3802972 | 21 x 1.5 | 26 | 294 | 1398 |
| 3800206 | 27 x 1.5 | 28,5 | 378 | 1656 |
| 3802973 | 31 x 1.5 | 30,5 | 434 | 1836 |
| 3800207 | 37 x 1.5 | 31,5 | 518 | 2024 |
| 3800208 | 48 x 1.5 | 36,8 | 672 | 2767 |
| 3800209 | 3 x 2.5 | 15,2 | 68,4 | 439 |
| 3800210 | 4 x 2.5 | 16,2 | 91,2 | 503 |
| 3800211 | 5 x 2.5 | 17,9 | 114 | 670 |
| 3800212 | 7 x 2.5 | 19 | 158,2 | 776 |
| 3800213 | 10 x 2.5 | 23,3 | 226 | 1145 |
| 3800214 | 12 x 2.5 | 24 | 271,2 | 1240 |
| 3800215 | 19 x 2.5 | 27 | 442 | 1630 |
| 3802974 | 21 x 2.5 | 28,1 | 488 | 1750 |
| 3800216 | 27 x 2.5 | 31,3 | 628 | 2115 |
| 3800217 | 37 x 2.5 | 36 | 860 | 2891 |
| 3800218 | 48 x 2.5 | 40 | 1,116.0 | 3555 |
| 3800219 | 3 x 4 | 18 | 110,4 | 666 |
| 3800220 | 4 x 4 | 19,2 | 147,2 | 770 |
| 3800221 | 5 x 4 | 20,4 | 184 | 874 |
| 3800222 | 7 x 4 | 21,8 | 257,6 | 1039 |
| 3800223 | 10 x 4 | 27,1 | 368 | 1532 |
| 3800224 | 12 x 4 | 27,8 | 441,6 | 1691 |
| 3800225 | 19 x 4 | 32 | 699,2 | 2292 |
| 3800226 | 27 x 4 | 39 | 993,6 | 3330 |
| 3800227 | 37 x 4 | 43,1 | 1,361.6 | 4147 |
| 3800228 | 48 x 4 | 50,2 | 1,766.4 | 5584 |
| 3802971 | 2 x 6 | 18,4 | 110,4 | 672 |
| 3800229 | 3 x 6 | 19,2 | 165,6 | 786 |
| 3800230 | 4 x 6 | 20,6 | 220,8 | 916 |
| 3800231 | 5 x 6 | 22 | 276 | 1058 |
| 3800232 | 3 x 10 | 21,2 | 277,8 | 1009 |
| 3800233 | 4 x 10 | 23,5 | 370,4 | 1333 |
| 3800234 | 5 x 10 | 25,2 | 370,4 | 1536 |
| 3803075 | 4 x 16 | 26,1 | 588,8 | 1736 |
| 3803076 | 4 x 25 | 30,5 | 926 | 2379 |
