ÖLFLEX® POWER LV (N)2XYRY
Low voltage power cables
- Low voltage power cable 0.6/1 kV
- Multicore, Armoured (SWA) XLPE/PVC/SWA/PVC
- product information (PDF)
■ Application range
- For main power distribution and lighting circuits in residential, industrial and commercial areas
- Power and control circuit
- Telecom power supply
- Suitable for direct burial installations as well as in air or ducts
■ Product features
- Cable construction in acc. to IEC 60502-1
- Flame-retardant acc. to IEC 60332-1-2
- UV-resistant outer sheath for outdoor application
■ Product Make-up
- Stranded plain annealed copper wires in circular or sectorial shape conductor
- XLPE core insulation
- PVC inner sheath, black
- Galvanized steel wire armoured
- PVC outer sheath, black
- Also available in LSHF version
■ Technical data
Core identification code
acc. to BS 7671:2004
Based on
IEC 60502-1
Specific insulation resistance
> 1000 GOhm x cm
Conductor stranding
acc. to IEC 60228 Cl.2
Minimum bending radius
10 x cable diameter
Nominal voltage
U0/U: 600/1000 V
Test voltage
3500 V
Temperature range
Fixed installation: -40°C to +90°C
| Article number | Number of cores and mm² per conductor | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| 2 core | ||||
| 3800330 | 2 x 1.5 | 13,4 | 28,2 | 323 |
| 3800333 | 2 x 2.5 | 14,3 | 46 | 374 |
| 3800336 | 2 x 4 | 15,4 | 73,6 | 445 |
| 3800339 | 2 x 6 | 17,2 | 110,4 | 610 |
| 3800342 | 2 x 10 | 19,1 | 184 | 775 |
| 3800345 | 2 x 16 | 21,2 | 294,4 | 980 |
| 3800348 | 2 x 25 | 25 | 460 | 1472 |
| 3800356 | 2 x 35 (S) | 27,7 | 644 | 1815 |
| 3800362 | 2 x 50 (S) | 30,8 | 920 | 2287 |
| 3800366 | 2 x 70 (S) | 36 | 1,288.0 | 3205 |
| 3800370 | 2 x 95 (S) | 40,5 | 1,748.0 | 4040 |
| 3800374 | 2 x 120 (S) | 44,2 | 2,208.0 | 4850 |
| 3800378 | 2 x 150 (S) | 49,8 | 2,760.0 | 6274 |
| 3800382 | 2 x 185 (S) | 54,8 | 3,404.0 | 7485 |
| 3800386 | 2 x 240 (S) | 61,2 | 4,416.0 | 9260 |
| 3800390 | 2 x 300 (S) | 66,8 | 5,580.0 | 11064 |
| 3 core | ||||
| 3800331 | 3 x 1.5 | 14 | 42,3 | 356 |
| 3800334 | 3 x 2.5 | 14,8 | 69 | 418 |
| 3800337 | 3 x 4 | 16 | 110,4 | 507 |
| 3800340 | 3 x 6 | 18 | 165,6 | 710 |
| 3800343 | 3 x 10 | 20 | 276 | 925 |
| 3800346 | 3 x 16 | 23 | 441,6 | 1350 |
| 3800350 | 3 x 25 | 26,7 | 690 | 1840 |
| 3800358 | 3 x 35 (S) | 29,5 | 966 | 2290 |
| 3800363 | 3 x 50 (S) | 32,7 | 1,380.0 | 2958 |
| 3800367 | 3 x 70 (S) | 38,7 | 1,932.0 | 4205 |
| 3800371 | 3 x 95 (S) | 43 | 2,622.0 | 5306 |
| 3800375 | 3 x 120 (S) | 48,2 | 3,312.0 | 6830 |
| 3800379 | 3 x 150 (S) | 53 | 4,140.0 | 8262 |
| 3800383 | 3 x 185 (S) | 58,3 | 5,106.0 | 9904 |
| 3800387 | 3 x 240 (S) | 65,2 | 6,624.0 | 12341 |
| 3800391 | 3 x 300 (S) | 71,2 | 8,280.0 | 14900 |
| 4 core | ||||
| 3800332 | 4 x 1.5 | 14,6 | 56,4 | 398 |
| 3800335 | 4 x 2.5 | 15,7 | 92 | 478 |
| 3800338 | 4 x 4 | 17,7 | 147,2 | 679 |
| 3800341 | 4 x 6 | 19,1 | 220,8 | 829 |
| 3800344 | 4 x 10 | 21,4 | 368 | 1093 |
| 3800347 | 4 x 16 | 24,7 | 588,8 | 1600 |
| 3800353 | 4 x 25 | 28,9 | 920 | 2228 |
| 3800359 | 3 x 35 +16 | 30,1 | 1,113.2 | 2521 |
| 3800361 | 4 x 35 (S) | 31 | 1,288.0 | 2817 |
| 3800364 | 3 x 50 +25 | 34,8 | 1,610.0 | 3560 |
| 3800365 | 4 x 50 (S) | 37 | 1,840.0 | 3990 |
| 3800368 | 3 x 70 +35 | 40 | 2,254.0 | 4688 |
| 3800369 | 4 x 70 (S) | 42,2 | 2,576.0 | 5222 |
| 3800372 | 3 x 95 +50 | 44,7 | 3,082.0 | 5984 |
| 3800373 | 4 x 95 (S) | 48,2 | 3,496.0 | 7064 |
| 3800376 | 3 x 120 +70 | 51 | 3,956.0 | 7869 |
| 3800377 | 4 x 120 (S) | 53,1 | 4,416.0 | 8609 |
| 3800380 | 3 x 150 +70 | 54,6 | 4,784.0 | 9172 |
| 3800381 | 4 x 150 (S) | 58,2 | 5,520.0 | 10352 |
| 3800384 | 3 x 185 +95 | 60,7 | 5,980.0 | 11204 |
| 3800385 | 4 x 185 (S) | 64,6 | 6,808.0 | 12530 |
| 3800388 | 3 x 240 +120 | 67,3 | 7,728.0 | 13891 |
| 3800389 | 4 x 240 (S) | 71,7 | 8,832.0 | 15668 |
| 3800392 | 3 x 300 +150 | 75 | 9,660.0 | 17661 |
| 3800393 | 4 x 300 (S) | 80,3 | 11,040.0 | 19982 |
| 5 core | ||||
| 3804054 | 5 x 1.5 | 15,5 | 70,5 | 445 |
| 3804055 | 5 x 2.5 | 17,4 | 115 | 627 |
| 3804056 | 5 x 4 | 18,8 | 184 | 774 |
| 3804057 | 5 x 6 | 20,4 | 276 | 950 |
| 3804058 | 5 x 10 | 23,6 | 460 | 1406 |
| 3804059 | 5 x 16 | 26,5 | 736 | 1867 |
| 3804060 | 5 x 25 | 31,4 | 1,150.0 | 2636 |
| 3804061 | 5 x 35 | 35,7 | 1,610.0 | 3626 |
| 6 core and above | ||||
| 3804062 | 7 x 1.5 | 17,1 | 98,7 | 607 |
| 3804063 | 12 x 1.5 | 20,6 | 169,2 | 837 |
| 3804064 | 14 x 1.5 | 21,4 | 197,4 | 909 |
| 3804065 | 16 x 1.5 | 23 | 225,6 | 1118 |
| 3804066 | 19 x 1.5 | 23,9 | 267,9 | 1210 |
| 3804067 | 24 x 1.5 | 26,8 | 338,4 | 1451 |
| 3804068 | 27 x 1.5 | 27,3 | 380,7 | 1536 |
| 3804069 | 37 x 1.5 | 30 | 521,7 | 1876 |
| 3804070 | 48 x 1.5 | 34,5 | 676,8 | 2497 |
| 3804071 | 7 x 2.5 | 18,4 | 161 | 736 |
| 3804072 | 12 x 2.5 | 23,1 | 276 | 1176 |
| 3804073 | 14 x 2.5 | 24 | 322 | 1286 |
| 3804074 | 16 x 2.5 | 25 | 368 | 1380 |
| 3804075 | 19 x 2.5 | 26 | 437 | 1525 |
| 3804076 | 24 x 2.5 | 29,6 | 552 | 1860 |
| 3804077 | 27 x 2.5 | 30,1 | 621 | 1982 |
| 3804078 | 37 x 2.5 | 34 | 851 | 2665 |
| 3802990 | 48 x 2.5 | 38,8 | 1,104.0 | 3325 |
