ÖLFLEX® POWER TPR 90 MC
Flexible power cables
- Highly flexible
- Oil- and UV-resistant
- product information (PDF)
■ Benefits
- Ideal alternative for H07RN-F with improve characteristics
- Highly flexible TPR insulated/sheathed multicore cable
■ Application range
- Connection of electrical equipment, drills, boilers, etc.
- For transportable motors or machines
- Suitable for power application
■ Product features
- Flame retardant acc. to AS/NZS 1660.5.6 resp. to IEC 60332-1-2
- Oil resistant acc. to IEC 60811-2-1
- UV-resistant outer sheath for outdoor application
■ Product Make-up
- Extra fine strands of bare copper wires
- TPR core insulation
- TPR outer sheath, black
■ Technical data
Core identification code
acc. to VDE 0293-308
Based on
AS/NZS 5000.1
Specific insulation resistance
> 20 GOhm x cm
Conductor stranding
Fine wire acc. to AS/NZS 1125 Cl.5 /
IEC 60228 Cl. 5
Minimum bending radius
occasional flexing: 15 x cable diameter
fixed installation: 5 x cable diameter
Nominal voltage
U0/U: 600/1000 V
Test voltage
3500 V
Temperature range
-30°C to +90°C
| Article number | Number of pairs/conductor cross section (mm²) | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
| 2 Core | ||||
| 3802900 | 2 x 1.5 | 11,2 | 28,8 | 121 |
| 3802901 | 2 x 2.5 | 12,2 | 48 | 159 |
| 3802902 | 2 x 4 | 13,4 | 76,8 | 218 |
| 3802903 | 2 x 6 | 14,7 | 115,2 | 302 |
| 3802904 | 2 x 10 | 16,9 | 192 | 573 |
| 3802905 | 2 x 16 | 19,4 | 307,2 | 766 |
| 3802906 | 2 x 25 | 23,1 | 480 | 1142 |
| 3802907 | 2 x 35 | 25,8 | 672 | 1483 |
| Full Earth | ||||
| 3801900 | 2×1+E | 11,1 | 29 | 121 |
| 3801901 | 2×1.5+E | 11,8 | 43 | 159 |
| 3801902 | 2×2.5+E | 12,9 | 72 | 218 |
| 3802910 | 2×4+E | 14,2 | 115,2 | 281 |
| 3802911 | 2×6+E | 15,6 | 172,8 | 392 |
| 3802912 | 2×10+E | 17,9 | 288 | 725 |
| 3802913 | 2×16+E | 20,6 | 460,8 | 991 |
| 3802914 | 2×25+E | 24,6 | 720 | 1479 |
| 3802915 | 2×35+E | 27,5 | 1,008.0 | 1927 |
| 3802916 | 2×50+E | 32,5 | 1,440.0 | 2649 |
| 3802917 | 2×70+E | 36,7 | 2,016.0 | 3467 |
| 3802918 | 2×95+E | 42,3 | 2,736.0 | 4315 |
| 3802919 | 2×120+E | 46,6 | 3,456.0 | 5376 |
| 3801911 | 3×1+E | 12 | 38 | 180 |
| 3801912 | 3×1.5+E | 12,8 | 58 | 219 |
| 3801913 | 3×2.5+E | 14 | 96 | 287 |
| 3802924 | 3×4+E | 15,5 | 153,6 | 354 |
| 3802925 | 3×6+E | 17,1 | 230,4 | 495 |
| 3802926 | 3×10+E | 19,7 | 384 | 921 |
| 3802927 | 3×16+E | 22,6 | 614,4 | 1249 |
| 3802928 | 3×25+E | 27,1 | 960 | 1879 |
| 3802929 | 3×35+E | 30,6 | 1,344.0 | 2449 |
| 3802930 | 3×50+E | 36,1 | 1,920.0 | 3380 |
| 3802931 | 3×70+E | 40,9 | 2,688.0 | 4427 |
| 3802932 | 3×95+E | 47,3 | 3,648.0 | 5550 |
| 3801926 | 4×1.5+E | 13,8 | 72 | 261 |
| 3801927 | 4x 2.5+E | 15,2 | 120 | 349 |
| 3802938 | 4×4+E | 16,9 | 192 | 438 |
| 3802939 | 4×6+E | 18,6 | 288 | 610 |
| 3802940 | 4×10+E | 21,6 | 480 | 1120 |
| 3802941 | 4×16+E | 24,9 | 768 | 1533 |
| 3802942 | 4×25+E | 30,1 | 1,200.0 | 2300 |
| 3802943 | 4×35+E | 34,2 | 1,680.0 | 3016 |
| 3802944 | 4×50+E | 40,2 | 2,400.0 | 4154 |
| 3802945 | 4×70+E | 45,5 | 3,360.0 | 5461 |
| 3801940 | 6×1.5+E | 14,9 | 100,8 | 330 |
| 3801942 | 11×1.5+E | 19,3 | 172,8 | 567 |
| 3801947 | 17×1.5+E | 22,5 | 259,2 | 811 |
| 3801948 | 26×1.5+E | 26,9 | 388,8 | 1177 |
| 3801949 | 35×1.5+E | 30,3 | 518,4 | 1525 |
| 3801941 | 6×2.5+E | 16,5 | 168 | 445 |
| 3801943 | 11×2.5+E | 21,5 | 288 | 760 |
| Reduced Earth | ||||
| 3801903 | 2×4+2.5E | 13,9 | 101 | 287 |
| 3801904 | 2×6+2.5E | 14,7 | 139 | 370 |
| 3801905 | 2×10+4E | 16,7 | 230 | 719 |
| 3801906 | 2×16+6E | 18,9 | 365 | 945 |
| 3801907 | 2×25+6E | 21,7 | 538 | 1383 |
| 3801908 | 2×35+10E | 24,4 | 768 | 1780 |
| 3801914 | 3×4+2.5E | 15,1 | 139 | 365 |
| 3801915 | 3×6+2.5E | 16,3 | 197 | 481 |
| 3801916 | 3×10+4E | 18,7 | 326 | 847 |
| 3801917 | 3×16+6E | 21,3 | 518 | 1148 |
| 3801918 | 3×25+6E | 24,7 | 778 | 1659 |
| 3801919 | 3×35+10E | 26,9 | 1,104.0 | 2190 |
| 3801920 | 3×50+16E | 32,7 | 1,594.0 | 3012 |
| 3801921 | 3×70+25E | 37,6 | 2,256.0 | 3975 |
| 3801928 | 4×4+2.5E | 16,6 | 178 | 453 |
| 3801929 | 4×6+2.5E | 17,9 | 254 | 598 |
| 3801930 | 4×10+4E | 20,6 | 422 | 1045 |
| 3801931 | 4×16+6E | 23,6 | 672 | 1463 |
| 3801932 | 4×25+ 6E | 27,7 | 1,018.0 | 2083 |
| 3801933 | 4×35+10E | 31,6 | 1,440.0 | 2738 |
| 3801934 | 4×50+16E | 37,2 | 2,074.0 | 3796 |
| 3801935 | 4×70+25E | 42,4 | 2,990.0 | 5471 |
