ÖLFLEX® POWER TPR 90 EARTH
Earth cables

Application range

  • Internal wiring of devices
  • Stranded hook-up wires for grounding connection of electrical eqipment and electronic components within devices

Product features

  • Flame retardant acc. to AS/NZS 1660.5.6 resp. to IEC 60332-1-2

Product Make-up

  • Extra fine strands of bare copper wires
  • TPR core insulation, green/yellow

Technical data

Core identification code
green/yellow
Based on
AS/NZS 5000.1
Specific insulation resistance
> 20 MOhm x km
Conductor stranding
Extra fine wire acc. to AS/NZS 1125 Cl.6 /
IEC 60228 Cl.6
Minimum bending radius
occasional flexing: 15 x cable diameter
fixed installation: 5 x cable diameter
Nominal voltage
U0/U: 600/1000 V
Test voltage
3500 V
Temperature range
-30°C to +90°C

Article number Conductor cross-section Outer diameter (mm) Copper index (kg/km) Weight (kg/km)
ÖLFLEX® POWER TPR 90 EARTH
3801520 6 5,6 57,6 70
3801521 10 6,8 96 112
3801522 16 8,1 153,6 171
3801523 25 9,7 240 255
3801524 35 11,2 336 351
3801525 50 12,7 480 488
3801526 70 14,9 672 685
3801527 95 16,9 912 914
3801528 120 19,6 1152 1191
