ÖLFLEX® H05RR-F

Application range

  • Hand-held and power supply devices
  • For dry and damp interiors, as well as for limited outdoor use
  • Light and sound applications
  • Light duty rubber-sheath cable
  • For light workshop devices with light stress

Product Make-up

  • Fine strands of bare copper wires
  • Rubber type EI4 core insulation
  • Rubber type EM3 outer sheath, black

Technical data

Core identification code
acc. to VDE 0293-308
Approvals
VDE 0282 Part 4
Specific insulation resistance
1 GOhm x cm
Conductor stranding
Fine wire acc. to IEC 60228 / VDE 0295 Cl.5
Minimum bending radius
6 x cable diameter
Nominal voltage
U0/U: 300/500 V
Test voltage
2000 V
Protective conductor
G = with protective conductor GN/YE
X = without protective conductor
Temperature range
-25°C to +60°C

Article number Number of cores and mm² per conductor Outer diameter (mm) Copper index (kg/km) Weight (kg/km)
3808120 2 X 0.75 5.7 – 7.4 14,4 61
3808121 2 X 1.0 6.1 – 8.0 19 73
3808122 2 X 1.5 7.6 – 9.8 29 115
3808123 2 X 2.5 9.0 – 11.6 48 160
3808124 2 X 4 10.6 – 13.7 77 192
3808125 2 X 6 12.1 – 15.4 115,2 250
3808130 3 G 0.75 6.2 – 8.1 21,6 75
3808131 3 G 1.0 6.5 – 8.5 29 86
3808132 3 G 1.5 8.0 – 10.4 43 135
3808133 3 G 2.5 9.6 – 12.4 72 190
3808134 3 G 4 11.3 – 14.5 115 255
3808135 3 G 6 12.8 – 16.3 173 350
3808140 4 G 0.75 6.8 – 8.8 30 91
3808141 4 G 1.0 7.1 – 9.3 38 105
3808142 4 G 1.5 9.0 – 11.6 58 165
3808143 4 G 2.5 10.7 – 13.8 96 235
3808144 4 G 4 12.7 – 16.2 154 327
3808145 4 G 6 14.2 – 18.1 230 449
3808150 5 G 0.75 7.6 – 9.9 45,2 110
3808151 5 G 1.0 8.0 – 10.3 48 128
3808152 5 G 1.5 9.8 – 12.7 72 190
3808153 5 G 2.5 11.9 – 15.3 120 285
3808154 5 G 4 14.6 – 18.6 192 401
3808155 5 G 6 16.8 – 20.4 288 550
