ÖLFLEX® H05RN-F
- VDE tested and certified
- product information (PDF)
■ Application range
- Hand-held and power supply devices
- For dry and damp interiors, as well as for limited outdoor use
- Medium duty rubber-sheathed cable
- For lightweight workshop tools subject to medium loads
■ Product features
- Flame retardant acc. to IEC 60332-1-2
■ Product Make-up
- Fine strands of bare copper wires
- Rubber type EI4 core insulation
- Rubber type EM2 outer sheath, black
■ Technical data
Core identification code
acc. to VDE 0293-308
Approvals
VDE 0282 Part 4
Specific insulation resistance
1 GOhm x cm
Conductor stranding
Fine wire acc. to IEC 60228 / VDE 0295 Cl.5
Minimum bending radius
6 x cable diameter
Nominal voltage
U0/U: 300/500 V
Test voltage
2000 V
Protective conductor
G = with protective conductor GN/YE
X = without protective conductor
Temperature range
-25°C to +60°C
Article number | Number of cores and mm² per conductor | Outer diameter (mm) | Copper index (kg/km) | Weight (kg/km) |
3808220 | 2 X 0.75 | 5.7 – 7.4 | 14,4 | 78 |
3808221 | 2 X 1.0 | 6.1 – 8.0 | 19 | 94 |
3808230 | 3 G 0.75 | 6.2 – 8.1 | 21,6 | 94 |
3808231 | 3 G 1.0 | 6.5 – 8.5 | 29 | 114 |
3808232 | 3 G 1.5 | 8.6 – 11.0 | 43 | 157 |
3808240 | 4 G 0.75 | 6.8 – 8.8 | 30 | 122 |
3808252 | 5 G 1.5 | 10.5 – 13.5 | 72 | 228 |
