ÖLFLEX® X01N2-D
- Arc welding cable acc. to VDE 0282-6
- product information (PDF)
■ Application range
- For transmitting high currents from the electric welding device to the welding tool
- Can be used in dry or damp rooms
■ Product features
- Flame retardant acc. to IEC 60332-1-2
■ Product Make-up
- Fine strands of bare copper wires
- Stranding approximately corresponds to class 6 for up to 95 mm2 , and class 5 for sizes from 120 mm2
- Separator made of PET tape
- EPR compound covering, type EM5
- Covering colour in Black or Orange
■ Technical data
Core identification code
black or orange
Based on
In acc. to VDE 0285 Part 6
Minimum bending radius
12 x cable diameter
Nominal voltage
U0/U: 100/100 V
Test voltage
1000 V
Temperature range
-25°C to +85°C
Article number | Conductor cross-section (mm²) | Outer diameter (mm) | Covering colour | Copper index (kg/km) | Weight (kg/km) |
Lapp Kabel X01N2-D | |||||
3808080 | 10 | 8,5 | black | 96 | 171 |
3808081 | 10 | 8,5 | orange | 96 | 171 |
3808082 | 16 | 9,5 | black | 154 | 198 |
3808083 | 16 | 9,5 | orange | 154 | 198 |
3808084 | 25 | 11,2 | black | 240 | 305 |
3808085 | 25 | 11,2 | orange | 240 | 305 |
3808086 | 35 | 12,5 | black | 336 | 415 |
3808087 | 35 | 12,5 | orange | 336 | 415 |
3808088 | 50 | 14,3 | black | 480 | 555 |
3808089 | 50 | 14,3 | orange | 480 | 555 |
3808090 | 70 | 16,5 | black | 672 | 765 |
3808091 | 70 | 16,5 | orange | 672 | 765 |
3808092 | 95 | 18,5 | black | 912 | 1010 |
3808093 | 95 | 18,5 | orange | 912 | 1010 |
3808094 | 120 | 20 | black | 1152 | 1262 |
3808095 | 120 | 20 | orange | 1152 | 1262 |
3808096 | 120 | 20 | black | 1152 | 1262 |
3808097 | 120 | 20 | orange | 1152 | 1262 |
3808098 | 185 | 25,5 | black | 1776 | 1995 |
3808099 | 185 | 25,5 | orange | 1776 | 1995 |
3808098 | 240 | 38,5 | black | 2304 | 2520 |
3808101 | 240 | 38,5 | orange | 2304 | 2520 |
